Configuring a Phantom Loop

Table 131
LD 17ÑSet up Phantom Loops
Chapter 12: Meridian 1 configuration for Meridian Link/CCR 349
A phantom loop is configured the same way as a normal loop with the
exception of a ÒCÓ preceeding the loop number. It is important that a
physical loop card be installed. A phantom DN can then be configured as
part of a specific device group. After configuration changes to the loop card,
the system must be reinitialized for the new settings to take effect. Phantom
loops are only supported as local terminal loops. For more information,
refer to X11 Software Features Guide (NTP 553-3001-305).
Note: The phantom terminal number of type ÒNÓ must not be used in
place of ÒCÓ.
Prompt Response
REQ CHG
TYPE CEQU
¥
¥
¥
TERM 0-159
(X) 0-159
(C) 0-159
TERD 0-159
(X) 0-159
(C) 0-159
TERQ 0-159
(X) 0-159
(C) 0-159
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Comment
Change
Common equipment
Press [Return] until the TERM prompt
appears.
Single density local terminal loops.
Precede loop number with X to remove.
Precede loop number with C to create a
phantom loop.
Double density local terminal loops.
Precede loop number with X to remove.
Precede loop number with C to create a
phantom loop.
Quad density local terminal loops.
Precede loop number with X to remove.
Precede loop number with C to create a
phantom loop.
