480 Chapter 15: Link configuration
Link 1ÑX.25 protocol (Meridian Link)
553-3202-210 Standard October 1998
Link 1 is defined as the host link using the X.25 protocol if services 97, 98,
100, or 101 are equipped with the following characteristics (which are
described in more detail later in this chapter):
Protocol: X25
Machine ID: x25dest
Delay: 0
Port type: X
PDN type: 44
Baud rate: 19200
RFS timer: 150
Remote address: 3
Maximum out frames (K): 7
Local DTE address: 000000990100
Flow control negotiation: 0
Outgoing packet size: 128
Outgoing window size: 2
Incoming throughput class: 10
Lowest LCN for DTE/DCE: Ð1
Lowest LCN: 1
LOC LIC: Ð1
T10: 1800
T11: 2000
T13: 1800
T15: 1500
Maximum T12 retries: 3
If your Meridian Link application requirements are satisfied by the default
configuration, no more procedures are required. You may choose to verify
the status of the link using Procedure 12: Verifying the link status, in this
chapter.
Link type: 2
Physical DTE(0)/DCE(1): 1
Maximum Frame length: 135
Fail timer: 150
Internal address: 1
T1: 30
Maximum trans attempts (N2): 7
Incoming packet size: 128
Incoming window size: 2
Throughput negotiation used: 0
Outgoing throughput class: 10
Highest LCN for DTE/DCE: Ð1
Highest LCN: 4095
HOC HIC: Ð1
T12: 1800
T14: 600
T16: 1300
Maximum T13 retries: 3
