Using Fast Demo Mode - Comtech EF Data CDM-710G Installation And Operation Manual

CDM-710G High-Speed Satellite Modem
FAST Activation Procedure
C.3

Using FAST Demo Mode

FAST Demo Mode may be enabled or disabled as follows:
a. Press [CLEAR] to return to the FAST menu:
b. Select Cnfg, then press [ENTER]:
c. Use the
d. Use the ◄ ► arrow keys to select Off or On. When On, the second line will display the
under of seconds remaining available for the free Demo Mode.
When enabled, Demo Mode allows access to ALL CDM-710G FAST options for 604800
seconds (7 full days). Demo Mode may be turned on and off an unlimited number of time
until the 604800 seconds have expired. The seconds count is only decrement when the
mode is On.
When the Demo period expires the following menu is displayed:
IF THE DEMO MODE STATE (OFF/ON) IS CHANGED, OR IF DEMO MODE IS
ENABLED AND THE TIMER EXPIRES, THE MODEM FIRMWARE WILL AUTO-
REBOOT AFTER 5 SECONDS.
IMPORTANT
NOTE THAT VALIDATION OF AUTHORIZED FAST OPTIONS OCCURS ON AUTO-
REBOOT;
CONFIGURATION WILL RESET TO DEFAULT VALUES.
FAST: Cnfg View
MainBoard S/N: 333333333
FAST Configuration:
Edit Code Demo Mode
◄ ► arrow keys to select Demo Mode, then press [ENTER].
FAST Demo Mode: Off
604800 seconds remain
FAST Demo Mode: Off
Demo Period Expired
IF AN INVALID
On
On
CONFIGURATION
C–4
Revision 1
MN-CDM710G
IS FOUND, THE MODEM
