CDM-710G High-Speed Satellite Modem
Front Panel Operation
Table 6-3. Statistics for the Gigabit Ethernet Interface
Category
Message
1000Base-T Link
Statistics
FPGA Link Errors
FPGA Overrun Errors
FPGA Rx Packets
FPGA Overflow Errors
FPGA Tx Packet Count
LAN Good Octets (In)
LAN Bad Octets (In)
LAN Unicast (In)
LAN Broadcast (In)
LAN Multicast (In)
LAN Pause (In)
LAN Undersize (In)
LAN Fragments (In)
LAN Oversize (In)
LAN Jabber (In)
LAN Rx Err (In)
LAN FCS Err (In)
LAN Octets (Out)
LAN Unicast (Out)
LAN Broadcast (Out)
LAN Multicast (Out)
WAN Port
WAN Octets (Out)
Statistics
WAN Unicast (Out)
WAN Broadcast (Out)
WAN Multicast (Out)
WAN Good Octets (IN)
WAN Unicast (IN)
WAN Broadcast (IN)
WAN Multicast (IN)
GBEI Statistics Summary
Indicates the number of HDLC link errors that have occurred on the Rx WAN interface. If the FPGA
Link Errors are incrementing while the Es/No or Eb/No is high, this often indicates the presence of
interference in the link.
Indicates the number of times that a GBEI buffer overrun has occurred in the Rx direction.
Indicates the number of Ethernet packets received from the WAN.
Indicates the number of times that a GBEI Rx buffer overrun condition has occurred.
Indicates the number of Ethernet packets transmitted to the WAN.
The sum of lengths of all good Ethernet frames received from the LAN.
The sum of lengths of all bad Ethernet frames received from the LAN.
The sum of good frames received from the LAN that have a unicast destination MAC address.
The sum of good frames received from the LAN that have a broadcast destination MAC address.
The sum of good frames received from the LAN that have a multicast destination MAC address.
The number of good flow control frames received from the LAN.
Total frames received from the LAN with a length of less than 64 octets but with a valid FCS.
Total frames received from the LAN with a length of less than 64 octets and an invalid FCS.
Total frames received from the LAN with a length greater than the maximum size of octets but with a
valid FCS.
Total frames received from the LAN with a length greater than the maximum size of octets but with an
invalid FCS.
Total frames received from the LAN for which an error was detected at the PHY.
Total frames received from the LAN with a CRC error that was not counted in the Fragments or Rx Err
totals.
The sum of the lengths of all Ethernet frames transmitted to the LAN.
The sum of frames transmitted to the LAN that have a unicast destination MAC address.
The sum of frames transmitted to the LAN that have a broadcast destination MAC address.
The sum of frames transmitted to the LAN that have a multicast destination MAC address.
The sum of the lengths of all Ethernet frames that are forwarded to the WAN.
The number of good frames with unicast destination MAC addresses that are forwarded to the WAN.
The number of good frames with broadcast destination MAC addresses that are forwarded to the WAN.
The number of good frames with multicast destination MAC addresses that are forwarded to the WAN.
The sum of lengths of all good Ethernet frames received from the IP encapsulation logic.
The sum of good frames received from the WAN IP encapsulation logic that have a unicast destination
MAC address.
The sum of good frames received from the WAN IP encapsulation logic that have a broadcast
destination MAC address.
The sum of good frames received from the WAN IP encapsulation logic that have a multicast
destination MAC address.
6–33
Description
Revision 1
MN-CDM710G
