7.1
Overview
This chapter describes the functionality of the CDM-710G High-Speed Satellite Modem Web
Server (HTTP) Interface. Please refer to Chapter 6. FRONT PANEL OPERATION, and the
Remote Commands Specifications tables found in Appendix A. REMOTE CONTROL for
detailed descriptions of the configuration parameters featured on the individual Web pages shown
in this chapter.
This interface is available via the RJ-45 J4 10/100 Ethernet Remote Port Connector on the rear
panel of the CDM-710G. Refer to Chapter 4. REAR PANEL CONNECTOR PINOUTS (Sect.
4.3.1) for details and pinout information.
Note: Only one remote method can be in control of either Ethernet or Serial, while the other can be
used for query.
7.1.1
Web Server Interface Introduction
The embedded Web Server application provides the user with an easy to use interface to configure
and monitor all aspects of the CDM-710G. These Web pages have been designed for optimal
performance when using Microsoft's Internet Explorer Version 5.5 or higher (the examples shown
in this chapter use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of
the CDM-710G from the Web Server Interface. By rolling
the cursor over the navigation tabs located at the top of
each page (right), the user can select from the available
nested hyperlinks.
Chapter 7. WEB SERVER
7–1
INTERFACE
