Comtech EF Data CDM-710G Installation And Operation Manual page 85

CDM-710G High-Speed Satellite Modem
Front Panel Operation
If Interface
In RS232 Mode the Bus
Address is fixed at 0000
If Interface
RS485 Mod Address: 0001
The valid range of addresses is from 1 to 9999. To edit the RS485 address of the modem, use the
arrow keys to select the digit to be edited, then use the
the digit. Press
If Serial CONFIG:
Local M&C Bus Baud Rate:
9600 Baud
Values of 1200, 2400, 4800, 9600, 19200, 38400, and 57600 baud are possible for the Baud rate
of the remote control bus connected locally to the M&C computer. Use the
change the value, then press
Note: The Asynchronous character format is FIXED at 8 data bits, No parity, and 1 stop bit (8-N-1).
(CONFIG:) Remote Control
Ethernet CONFIG: Gateway
Address
Select Gateway, Address, MAC, or SNMP using the
If Ethernet CONFIG:
Ethernet IP Gateway:
063.168.001.127
Use the ◄ ► arrow keys to select the digit to be edited, then use the
value of the digit. Press
If Ethernet CONFIG:
Ether IP Address/Range:
192.168.001.001/24
The range is adjustable from 08 to 30. Use the
use the arrow keys to change the value of the digit. Press
RS232 is selected:
RS485 is selected, the user will be further prompted:
(
when done.
ENTER
Baudrate is selected:
( E )
.
ENTER
MAC SNMP (
Gateway is selected:
(
when done.
ENTER
Address is selected:
(
E)
Ethernet
E)
arrow keys, then press
E )
)
arrow keys to select the digit to be edited, then
ENTER
6–9
MN-CDM710G
arrow keys to change the value of
arrow keys to
ENTER
arrow keys to change the
when done.
Revision 1
.
