CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Unit Alarm
MSK=
13 bytes
Mask
Soft Reboot
RBT=1
1 byte
Retrieve next 5
N/A
75 bytes
unread Stored
Events
Description of Arguments
Query
Command or Query.
Alarm mask conditions, in form ab, where:
a=Tx Cable Slot 1
b=Tx AIS Slot 1
c=Rx AIS Slot 1
d=Bufferslip Alarm Slot 1
e=External Clock Alarm Slot 1
f=Tx Cable Slot 2
g=Tx AIS Slot 2
h=Rx AIS Slot 2
i=Bufferslip Alarm Slot 2
j=External Clock Alarm Slot 2
k=EBNO Alarm
L=Ber Alarm
m=Rx AGC Alarm xxx -spares
Mask (Alarm=0, Fault = 1,Masked =2))
Example: MSK=110101100000xxx ( alarm masks for Interface Slot 1 ,Slot 2 ,
Command Only.
Soft Reboot.
1= Reboot System
Query Only.
Unit returns the oldest 5 Stored Events which have not yet been read over
the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where:
Sub-body= ABCddmmyyhhmmss,
A being the fault/clear indicator.
F=Fault
C=Clear
I=Info
B being the fault type where:
1=Unit
2=Rx Traffic
3=Tx Traffic
4=Log
C is Fault Code numbers, as in FLT? or Info Code, which is:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
If there are less than 5 events to be retrieved, the remaining positions are
padded with zeros. If there are no new events, the response is RNE*.
A–11
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
MSK=
MSK?
MSK=abcdefghijkLmxxx
MSK?
MSK*
MSK#
RBT?
N/A
RBT=
RBT*
RBT#
RNE?
RNE?
RNE={CR}ABCddmmyyh
RNE*
hmmss{CR}ABCddmmyy
RNE#
hhmmss{CR}ABCddmm
yyhhmmss{CR}ABCddm
myyhhmmss
{CR}ABCddmmyyhhmm
ss
Revision 1
MN-CDM710G
