CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Tx Output
IMP=
1 byte
Impendance
IP Address
IPA=
18 bytes
Equipment ID
N/A
23 bytes
Description of Arguments
Query
Command or Query.
Tx output impedance, where:
0=50 Ohm
1=75 Ohm
Example: IMP=0 (Set impedance to 50 Ohms)
* NOTE: Setting Tx Impedence is only possible on 70/140 Mhz units.
Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseTx
Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (00..31)
Example: IPA=010.006.030.001.24
Query Only.
Unit returns equipment identification and configuration, where:
aaa = defines the modulator model number (71G)
b = Modulator configuration:
1=70/140 Mhz, 2=L-Band
c = Tx Symbol Rate S/W option: 0 = 15.0 Msps,
1 = 22.5 Msps, 2 = 30.0 Msps,
3 = 37.5 Msps (S1 and DSNG only),
4 = 45.0 Msps (S1 and DSNG only)
d = S/W option Tx 8PSK: 0=Not installed, 1=Installed
e = S/W option Tx 16-QAM: 0=Not installed, 1=Installed
f = S/W option Tx 16APSK: 0=Not installed, 1=Installed
g = S/W option Tx 32APSK: 0=Not installed, 1=Installed
h = S/W option Tx DVB-S1: 0=Not installed, 1=Installed
i = S/W option Tx DVB-DSNG: 0=Not installed, 1=Installed
j = S/W option Tx DVB-S2: 0=Not installed, 1=Installed
k = Demodulator configuration:
0=None, 1=70/140 Mhz, 2=L-Band
l = Rx Symbol Rate S/W option: 0=15.0 Msps,
1 = 22.5 Msps, 2 = 30.0 Msps,
3 = 37.5 Msps (S1 & DSNG only),
4 = 45.0 Msps (S1 & DSNG only)
m = S/W option Rx 8PSK: 0=Not installed, 1=Installed
n = S/W option Rx 16-QAM: 0=Not installed, 1=Installed
o = S/W option Rx 16APSK: 0=Not installed, 1=Installed
p = S/W option Rx 32APSK: 0=Not installed, 1=Installed
q = S/W option Rx DVB-S1: 0=Not installed, 1=Installed
r = S/W option Rx DVB-DSNG:0=Not installed, 1=Installed
s = S/W option Rx DVB-S2: 0=Not installed, 1=Installed
t = Interface slot #1: 0 = None, 1 = Reserved, 2 = Gigabit Ethernet
Interface, 3 = HSSI, 4 = E3T3STS1
u = Interface slot #2: 0 = None, 1 = Reserved, 2 = Gigabit Ethernet
Interface, 3 = HSSI, 4 = E3T3STS1
Response to
IMP=
IMP?
IMP*
IMP#
IPA=
IPA?
IPA*
IPA#
EID?
EID*
EID#
A–8
MN-CDM710G
Query
(Instruction
Response to Query
Command
Code and
Qualifier)
IMP?
IMP=x
IPA?
IPA= xxx.xxx.xxx.xxx.yy
EID?
EID=
aaabcdefghijklmnopqrstu
Notes:
Unit returns 'Not
Installed' for Rx options if
unit is modulator only.
Unit returns 'Not
Installed' for Tx options if
unit is demodulator only.
Revision 1
