CDM-710G High-Speed Satellite Modem
Front Panel Operation
6.3.1.9

CONFIG: Alarms

Note: When the unit is in Remote mode and the user attempts to select an alarm state using the
arrow keys, the following message displays (follow the prompt as shown):
THIS UNIT IS CURRENTLY
IN REMOTE MODE!!
DO YOU WANT IN LOCAL
MODE?ENT=Yes CLR=No
Otherwise, the following menu is displayed:
Alarm Mask: Tx Rx
Intfc1 Intfc2
Select Tx, Rx, Intfc1, or Intfc2 using the
(CONFIG:) Alarm Mask:
Tx Alarm Mask: None
Currently, masking of Tx Alarms (associated with the modulator) is not allowed.
(CONFIG:) Alarm Mask:
Eb/No Threshold Alarm:
Alarm Fault
Select Alarm, Fault, or Mask using the
(CONFIG:) Alarm Mask:
The appearance of the menu branch for CONFIG: Alarms (Alarm Mask:)
dependent on whether the CDI-10-1 Single G.703 or the CDI-60 HSSI Interface card is installed
into Interface Slot 1.
Intfc1 E3T3STS1 Alarms:
Tx Rx ExtClk
Intfc1 HSSI Alarms:
Port1 Ext-Clk
( E)
Tx
Rx
Mask ( E)
Intfc1
( E)
( E)
6–37
arrow keys, then press
arrow keys, then press
ENTER
Revision 1
MN-CDM710G
.
ENTER
.
Intfc1 is
