CDM-710G High-Speed Satellite Modem
Remote Control
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Redundancy RED= 1 byte, value of
State 0 or 1
Restore Factory RFD= 0Bytes
Defaults
Rx Buffer RFM= 3 bytes
Frame
Rx Frequency N/A 5 bytes
Offset
Rx Frequency RFQ= 9 bytes
Rx Frame Size N/A 1 byte
Description of Arguments
Query
Command or Query.
Unit returns the redundancy state of the unit, where:
0 = Offline
1 = Online
*** This command can be used to force the unit offline, this is done by
sending RED=0. This is only valid if redundancy mode is enabled. If
redundancy is not enabled, then RED=0 will return an error. The unit
cannot be forced online.
*** If the unit is not in redundancy mode, then the unit will always be online.
Example: RED=0 (force unit offline)
Command Only
Restore Modem to Factory Defaylts
Command or Query. (G.703 Parameters)
Rx Buffer Frame, where:
s=Defines which interface slot ( 1 or 2 )
x=Rx Ternary Code, where:
0=None ( Valid for E3, T3, and STS-1 )
1=G.751 (Valid for E3 )
2=G.752 (Valid for T3 )
3=G.753 (Valid for E3 )
4=STS-1 (Valid for STS-1 )
Note: Command valid only with CDI-10-1l G.703 interface.
Example: RFM=11 (selects G.751 for slot #1, channel #1)
Query only.
Unit returns the value of the measured frequency offset of the carrier being
demodulated. Values range from ± 0 to ± 100 kHz, 100 Hz resolution.
Returns 999999 if the demodulator is unlocked.
Example: RFO=+002.3 (which is + 2.3 kHz)
Command or Query.
Rx Frequency (in MHz)
52 to 88 MHz, and 104 to 176 MHz (70/140 Modulator)
950 to 1950 MHz (L-Band Modulator)
Resolution=100Hz.
Example: RFQ=0950.0000
Query Only.
Rx Frame Size Long/Short selection, where:
0=Short,
1=Long
Example: RFS =0 (which is Short Frame Size)
*NOTE: This is automatically detected on demod acquisition, but if the unit
is not locked, the query returns 'x'.
A–24
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RED= RED? RED=x
RED? (see description of
RED* arguments)
RED#
RFD= RFD= N/A
RFM= RFM?s RFM=sx
RFM? (see description of
RFM* arguments)
RFM#
RFO? RFO? RFO=sxxx.x
RFO*
RFO#
RFQ= RFQ? RFQ=xxxx.xxxx
RFQ?
RFQ*
RFQ#
RFS? RFS? RFS =x
RFS #
Revision 1
MN-CDM710G
