CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Tx Data Invert
TDI=
2 bytes
Tx Data Rate
N/A
10 bytes
Tx Frequency
TFQ=
9 bytes
Tx Frame Size
TFS=
1 byte
Tx FEC Type
N/A
1 byte
Tx Gold Code
TGS=
6 bytes
Sequence Index
Tx Interface
TIE=
2 bytes
Enable
Description of Arguments
Query
Command or Query.
Invert Transmit Data, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Transmit Data, where:
0=Normal
1=Inverted
Note: Command valid with HSSI or E3T3STS1)
Example: TDI = 11 (selects Inverted TX Data)
Query Only.
Composite Tx Data rate, in kbps.
Resolution=1 bps.
Example: TDR=002047.999 (which is 2047.999 kbps)
Command or Query.
Tx Frequency (in MHz)
52 to 88 MHz, and 104 to 176 MHz (70/140 Modulator)
950 to 1950 MHz (L-Band Modulator)
Resolution=100Hz.
Example: TFQ=0950.0000
Command or Query.
Tx Frame Size Long/Short selection, where:
0=Short,
1=Long
Example: TFS =0 (which is Short FEC Frame Size)
Query Only.
Tx FEC coding type, where:
1=LDPC
( FEC is dependent on the TX Mode Type. )
Example: TFT=1 (which is LDPC coding)
Command or Query.
Tx Gold Code Sequence Index:
xxxxxx = Gold Code Sequence index ( 0 to 262141 )
Example: TGS=189063
Command or Query.
Interface Slot Enable/Disable, where:
s=Defines which interface slot (1 or 2)
x=Tx Interface Status, where:
0=Disabled
1=Enabled
Example: TIE =11 (Enables transmit interface)
TDI =
TDI?
TDI *
TDI #
TDR?
TDR*
TDR#
TFQ=
TFQ?
TFQ*
TFQ#
TFS =
TFS?
TFS *
TFS #
TFT?
TFT*
TFT#
TGS=
TGS?
TGS*
TGS#
TIE=
TIE?
TIE*
TIE#
A–13
MN-CDM710G
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
TDI?sc
TDI =sx
(see description of
arguments)
TDR?
TDR=xxxxxx.xxx
TFQ?
TFQ=xxxx.xxxx
TFS?
TFS =x
TFT?
TFT=x
TGS?
TGS=xxxxxx
TIE?s
TIE=sx
Revision 1
