SELECT: Monitor

Monitor: Alarms
Event-Log
Alarms are reported under three main categories:
•
Tx path alarms are displayed under the Tx Category
•
Rx path alarms are displayed under the Rx Category
•
Alarms common to the unit are available under the Unit selection
Refer to Table 6-4 for a listing of alarms.
Select Alarms, Rx_Stats, or Event-Log using the ◄ ► arrow keys, then press
6.3.2.1 (SELECT:) Monitor
Live Alarms: Transmit
Receive
Select Transmit, Receive, or Unit using the ◄ ► arrow keys, then press
If Live Alarms:
TX Traffic:
PHY Not Connected
This will report only if there are modulator errors; otherwise, it will report "No Errors." Press
or
ENTER CLEAR
NOTE: The alarm message depicted in the above example usually indicates that the Ethernet data
cable is disconnected from the modem.
If Live Alarms:
RX Traffic:
Demod Unlocked
This will report only if Demod is unlocked; otherwise, it will report "No Errors." Press
or to return to the previous menu.
CLEAR
If Live Alarms:
Unit Fault: No Errors
This will report only if there are unit faults; otherwise, it will report "No Errors." Press
or to return to the previous menu.
CLEAR
Rx_Stats
Alarms
Unit ( E)
Transmit is selected:
GBEI Card
(E)
to return to the previous menu.
Receive is selected:
(E)
Unit is selected:
(E)
