Chapter 6. FRONT PANEL
OPERATION
6.1
Introduction
LED
Vacuum Fluorescent
Indicators
Keypad
Display (VFD)
Figure 6-1. CDM-710G Front Panel View (L-Band version shown)
The user can fully control and monitor the operation of the CDM-710G from the front panel using
the keypad and display. Nested menus are used that display all available options and prompt the
user to carry out a required action.
Figure 6-1 identifies the key features of the front panel that are explained in greater detail in this
section.
