CDM-710G High-Speed Satellite Modem
Front Panel Operation
If the selected location contains valid data, what displays is similar to the following example:
New Config has been
Loaded from Loc #
Press or
ENTER
If the selected location contains invalid data, what displays is similar to the next example:
Warning! Loc 9 Contains
No Data!
Press or
ENTER
6.3.6

SELECT: Util (Utility)

UTIL: RT-Clk Ref ID
Display Firmware FAST
Select RT-Clk, Ref, ID, Display, Firmware, or FAST using the
.
ENTER
6.3.6.1 (SELECT:) UTIL
Edit Real-Time Clock:
10:23:51 23/05/06 (
Edit the time and date settings of the real-time clock. Use the
Use the arrow keys to change the value of the digit, then press
Note: In accordance with international convention, the date is shown in DAY/MONTH/YEAR
format.
6.3.6.2 (SELECT:) UTIL
Internal 10 MHz Ref Freq
Fine Adjust:+1911
This menu provides a fine adjustment for the internal 10 MHz reference.
For 'Tx Only' or 'Full Duplex' units, use the Tx IF Carrier to check the reference frequency by
first placing the unit in the
In 'Rx Only' units, 10 MHz is available at J6-8 or J6-9 only while within the
(E)
to return to the previous menu.
CLEAR
(E)
to return to the previous menu.
CLEAR
RT-Clk
Ref
Tx-CW mode from the
E)
menu.
Test
6–49
Revision 1
MN-CDM710G
arrow keys, then press
arrow keys to select the digit.
.
ENTER
menu.
Utility: Ref
