CDM-710G High-Speed Satellite Modem
Front Panel Operation
If Firmware Info:
Bootrom:
CDM710_Boot
This screen provides information on the installed Bootrom firmware. The release date is provided
on the top line in DAY/MONTH/YEAR format; the bottom line identifies the installed Firmware
by its release name/number and its version number.
Note: The firmware information shown above is representative. Current status is obtained via the
Firmware Info:
Press
or
ENTER
If Firmware Info:
Image#x: Bulk
FEC Mod
On the next page, Table 6-5 provides an overall summary of examples for each available
firmware info screen. As shown, the first column for either Image provides the available
selection; the second column provides an example of the information provided for that selection.
Note: The information in this table is representative; the firmware numbers/revision
letters/versions/release dates are subject to change.
(Firmware:) Firmware Images
Current Active Image: #2
Next Reboot Image: #1 #2
The top line shows the active image. To select the active software image, on the second line, select
the desired image using the
To make the selected image the active choice, power cycle the modem to reboot the new software.
Bootrom is selected:
07/17/06
1.1.1
Bootrom submenu.
to return to the previous menu.
CLEAR
Image#1 or
Image#2 is selected:
App
Framer
Demod
Interfaces
arrow keys, then press
Select
.
ENTER
6–51
Revision 1
MN-CDM710G
