CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
E3/T3/STS1
ETS=
2 bytes
Mode Select
Gigabit
GIP=
19 bytes
Management IP
Address and
Subnet
Gigabit
GMC?
N/A
Interface
Management
MAC Address
Gigabit
GSW?
N/A
Interface
Software
Revision
Initialize Events
IEP=
None
Pointer
Boot Image
IMG=
1 byte
Tx Output
IMP=
1 byte
Impendance
Description of Arguments
Query
Command or Query.
Sets the E3/T3/STS1 interface card mode.
s=Interface Slot (1 or 2)
m=Mode
0=E3
1=T3
2=STS1
Note: Command valid only with CDI-10-1 G.703 interface. This sets the
selected G.703 DATA rate. The unit will adjust the symbol rate based on
modulation type and code rate to keep the selected data rate.
Example: ETS=11 (sets Interface 1, Port 1 to T3 mode)
Command or Query.
Gigabit Management IP address and subnet mask.
s= Slot2 Only i=IP Address
n=Netmask
Query Only.
s=Defines Interface slot (2)
Example: To get MAC address for Gigabit in Slot 1
GMC?2
GMC=2s0006B0004717
Query Only.
s=Defines Interface slot (2)
Example: To get Software Revision for Gigabit in Slot 2
GSW?2
GSW=2FW/12738-,1.1.8,02/16/07
Command Only.
Resets internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
Command or Query.
Boot image selection, where n is the image number:
1=Image #1
2=Image #2
Example: IMG=1 (Selects Image #1 for booting.)
Command or Query.
Tx output impedance, where:
0=50 Ohm
1=75 Ohm
Example: IMP=0 (Set impedance to 50 Ohms)
* NOTE: Setting Tx Impedence is only possible on 70/140 Mhz units.
ETS=
ETS?
ETS#
ETS*
GIP=
GIP#
GIP?
GIP*
GMC?
GMC*
GMC#
GSW?
GSW*
GSW#
IEP=
IEP?
IEP*
IEP#
IMG=
IMG?
IMG*
IMG#
IMP=
IMP?
IMP*
IMP#
A–20
MN-CDM710G
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
ETS?s
ETS=sm
GIP?s
GIP=siii.iii.iii.iii.nn
GMC?s
Gigabit Interface
Management
MAC Address
GSW?s
Gigabit Interface
Software Revision
N/A
IEP=
IMG?
IMG=n
IMP?
IMP=x
Revision 1
