CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
IP Address
IPA=
18 bytes
Gateway
IPG=
15 bytes
Address
Interface Type
N/A
2 bytes
Rx Link Margin
N/A
4 bytes
Local/Remote
LRS=
1 byte
Status
Unit MAC
N/A
12 bytes
Address
Description of Arguments
Query
Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseTx
Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (00..31)
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the Gateway IP addess for the 10/100 Base Tx Ethernet
management port, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 010.006.030.001
Query Only.
Interface Type, where:
s=Defines which interface slot (1 or 2)
x=Defines the interface type, where:
0=Reserved
1= Reserved
2= Gigabit Ethernet
3= HSSI
4= E3T3STS1
Example: ITF?1
Query only.
Unit returns the value of the Link Margin.
Returns 00.0 if demod is unlocked.
Example: LNK=12.3
Command or Query.
Local/Remote status, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
Example: LRS=1 (which is remote Serial)
Query Only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=0006B000D2A7
(The MAC address of the unit is 00:06:B0:00:D2:A7 )
Response to
IPA=
IPA?
IPA*
IPA#
IPG=
IPG?
IPG*
IPG#
ITF?
ITF*
ITF#
LNK?
LNK*
LNK#
LRS=
LRS?
LRS*
LRS#
MAC?
MAC*
MAC#
A–38
MN-CDM710G
Query
(Instruction
Response to Query
Command
Code and
Qualifier)
IPA?
IPA= xxx.xxx.xxx.xxx.yy
IPG?
IPG = xxx.xxx.xxx.xxx
ITF?s
ITF=sx
LNK?
LNK=xxxx
LRS?
LRS=x
MAC?
MAC=AABBCCDDEEFF
Revision 1
