6.3.4 SELECT: INFO

Note: INFO screens provide read-only information on the current configuration of the modem
without risking inadvertent changes. The user may only view, but not edit, an Info screen.
INFO: Rem
Intfc1 Intfc2
Select Rem, Tx, Rx, Intfc1, or Intfc2 using the ◄ ► arrow keys, then press
6.3.4.1 (SELECT:) INFO
Remote M&C: 100BaseTx
IP Addr: 192.168.001.006
This display provides the status, as applicable, of the Remote Monitor & Control configuration.
6.3.4.2 (SELECT:) INFO
Tx: 0140.0000
DVBS2 8P 3/4
Using the example shown, a typical transmit data info screen may be broken down as follows:
Value
Tx: 0140.0000
17.379483
DVBS2
8P
3/4
-10.0
ON
Tx Rx
( E)
Rem
Tx
17.379483
-10.0 ON
Description
Tx Frequency in MHz
Data rate in Mbps
Transmission mode
(Modulation:)
QP=QPSK
8P=8-PSK
16A=16-APSK
32A=32-APSK
Code Rate
Tx Power level in dBm
Tx Power: ON = On, OF = Off
