CDM-710G High-Speed Satellite Modem
Introduction
1.3

Features

1.3.1

Physical Description

The CDM-710G is constructed as a 1RU-high rack-mount chassis, which can be free-standing if
desired. Rack handles at the front facilitate removal from and placement into a rack.
The operator may configure and monitor the CDM-710G from the front panel, or through the
remote M&C port. Control and status is provided through the RS-232, RS-485 (2Wire or 4Wire)
port or 10/100 Base-T Ethernet port. The management Ethernet port supports SNMP, Telnet and
HTTP (Web browser) operation.
1.3.2

Major Assemblies

Assembly
PL/10002-1
PL/12113-1
PL/10003-1
PL/11571-1
PL/12148-1
PL/12169-1
PL/10008-2
PL/11582-1
PL/11509-3
Description
Modulator, 70/140 MHz
Modulator, L-Band Card
Demodulator, 70/140 MHz
Demodulator, L-Band
Encoder Assembly, Tx DVB-S2 Long/Short Frame
Decoder Assembly, Rx DVB-S2 Long/Short Frame
CDI-10-1 G.703 Interface
CDI-60 HSSI Interface
CDI-70 10/100/1000 Base-T Ethernet (GigE) Interface (FW12738)
1–5
Revision 1
MN-CDM710G
