CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Rx Symbol Rate RSR=
9 bytes
Enable/Disable
AEQ=
1 byte
Adaptive
Equalizer
Buffer Fill State
N/A
3 bytes
Rx BER Alarm
BTH
1bytes
Threshold
Clear All Stored
CAE=
None
Events
Circuit ID String
CID=
24 bytes
Configuration
CLD=
1 byte
Load
Description of Arguments
Query
Command or Query.
Rx Symbol Rate, where:
s=Symbol Rate in Msps
Example: RSR=20.000000 (20 Msps.)
*NOTE: Please refer to Sect. 1.8 Summary of Specifications for a list of
available code rates for each modulation type.
Command or Query.
Adaptive Equalizer status, where:
0=Disable
1=Enable
Example: AEQ=1 (which is Enable)
Query only.
s=Defines which interface slot ( 1 or 2 )
xx = value of the buffer fill state, between 1 to 99%. Returns 00 if
demodulator is unlocked.
Note: Command not valid for Gigabit interface.
Example: BFS=133 (which is 33%, on interface slot 1 channel 1)
Command or Query.
Sets and Returns BerThreshold
a=Ber Threshold
0= NONE
3= 1E10-3
4 =1E10-4
5= 1E10-5
6= 1E10-6
7= 1E10-7
8 =1E10-8
Example BTH=3(Sets Ber Alarm Threshold to 1E10-3)
Command Only.
Forces the software to clear the software events log.
Example: CAE=
Note: This command takes no arguments
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed length of
24 characters.
Valid characters include: Space ( ) * + – , . / 0 9 and A thru Z
Command Only.
Retrieves a previously stored configuration from the specified configuration
location (0 to 9).
Example: CLD=4 (retrieve configuration from location 4)
RSR=
RSR?
RSR*
RSR#
AEQ=
AEQ?
AEQ*
AEQ#
N/A
BTH=
BTH?
BTH#
CAE=
CAE?
CAE*
CAE#
CID=
CID?
CID*
CID#
CLD=
CLD?
CLD*
CLD#
A–16
MN-CDM710G
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
RSR?
RSR=ss.ssssss
AEQ?
AEQ=x
BFS?s
BFS=sxx
BTH=a
BTA=a
N/A
N/A
CID?
CID=xxxxxxxxxxxxxxxxx
xxxxxxx
N/A
N/A
Revision 1
