CDM-710G High-Speed Satellite Modem
Front Panel Operation
6.3.1
(SELECT:) Config
CONFIG: Remote Tx Rx
Int1 Int2 Ref Aux Alarms
The submenus available are:
SELECTION
SECT
6.3.1.1
Remote
6.3.1.2
Tx
6.3.1.3
Rx
6.3.1.4
Int1
6.3.1.5
6.3.1.6
Int2
6.3.1.7
Ref
6.3.1.8
Aux
6.3.1.9
Alarms
The modem may be monitored over the remote control bus at any time. When
in Local mode, however, configuration parameters may only be changed
through the front panel. Conversely, when in Remote mode, the unit may be
monitored from the front panel, but configuration parameters may only be
IMPORTANT
changed via the remote control bus.
SUBMENU DESCRIPTION
(Remote Control) Permits defining whether the unit is being controlled
locally or remotely (see IMPORTANT note).
(Transmit) Permits defining, on a parameter-by-parameter basis, the Tx
configuration of the unit. These submenu branches would be used if the
user wished to change, e.g., just the Tx Frequency.
(Receive) Permits defining, on a parameter-by-parameter basis, the Rx
configuration of the unit. These submenu branches would be used if the
user wished to change, e.g., just the Rx Frequency.
(Interface) Permits configuring Interfaces plugged into Slot 1 or Slot 2 on
the back of the unit. The menus change depending on the type of interface
– as of this manual revision, Single G.703, HSSI, or Gigabit Ethernet (GigE)
are available:
Int1 CDI-10-1 Single G.703 Interface only.
Int1 CDI-60 HSSI Interface only.
Int2 CDI-70 Gigabit Ethernet Interface only.
(Reference) Permits selection of the internal 10MHz Reference or allows
the unit to phase lock to an External Reference of 1, 2, 5, 10, or 20 MHz.
The unit reverts to Internal if the External Reference is not present or is
faulted.
(Auxiliary) Permits configuring the 1:1 Modem Switching parameters of the
unit.
Provides Alarm action of certain parameters.
6–7
Revision 1
MN-CDM710G
