CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Faults and
N/A
5 Bytes
Status
Description of Arguments
Query
Query Only.
Unit returns the current fault and status codes for the Unit (hardware), Tx
Traffic and Rx Traffic, in the form abcd, where:
a = Unit Faults:
0=No faults
1=Framer FPGA Load
2=Power supply fault, +1.5 Volts, Framer Card
3=Power supply fault, +1.5 Volts, Interface #1
4=Power supply fault, +1.5 Volts, Interface #2
5=Power supply fault, +3.3 Volts, Framer Card
6=Power supply fault, +5.0 Volts, Framer Card
7=Power supply fault, +12.0 Volts, Framer Card
8=Power supply fault, -12.0 Volts, Framer Card
9=Power supply fauilt, +18.0 Volts, Framer Card
A=FLASH Checksum
B=FEC1 Load
C=FEC2 Load
D=Interface #1 Load
E=Interface #2 Load
F=192 MHz PLL
G=External Reference
H=Framer Card Temperature
I=Modem Temperature
J=Cooling Fans
K=Interface #1 Removed
L=Interface #2 Removed
M=Reserved(Unit Factory Fault)
N=Interface1 Wrong Type
O=Interface2 Wrong Type
b = Tx Traffic Status:
0=No faults
1= +1.5V Power Supply Unit (Modulator Card)
2= FPGA Failed to Load (Modulator Card)
3= Symbol Rate PLL Clock
4= Tx Synthesizer Unlocked
5= Tx Digital Clock Manager Unlocked
6= I & Q Baseband Channels are Inactive
7= FPGA Temperature (Modulator Card)
8= Reserved
9= TX Clock Failure (Interface 1)
A= TX Clock Failure (Interface 2)
B= GBEI Card Data rate > + 200 PPM
C= GBEI Card Data rate < - 200 PPM
D= GBEI No PHY Link
Response to
FLT?
FLT*
FLT#
A–35
MN-CDM710G
Query
(Instruction
Response to Query
Command
Code and
Qualifier)
FLT?
FLT=abcde
d=Change in fault status
since last poll.
Note: Each section has
faults listed in order of
priority. For each
section, only the highest
priority fault is returned.
There maybe multiple
faults for each section,
but only the highest fault
is returned.
e=Configuration Change
Revision 1
