CDM-710G High-Speed Satellite Modem
Remote Control
[Tx Block] consists of 50 bytes for Transmit configuration. The format is: aaaa.aaaabcc.ccccccdefghhh.hijklmmmmmmnoxxxxxxxxxx
aaaa.aaaa = Tx Frequency (in MHz)
b = Tx Mode
cc.cccccc = Tx Symbol Rate
d = Tx FEC Type
e = Tx Modulation type
f = Tx FEC Rate
g = Tx Spectrum Inversion
hhh.h = Tx Power Level
i = Tx Carrier State
j = Tx Alpha Roll-off
k = Tx Frame Size
l = Tx Pilots
mmmmmm = Tx Gold Code Sequence same as TGS
n = Tx Location of Pilot
o = Tx Transport Stream
xxxxxxxxxx = Spare bytes.
[Rx Block] consists of 50 bytes for Receive configuration. The format is: aaaa.aaaabcc.ccccccdefggghijkllllllmm.mnopxxxxxxxx
aaaa.aaaa = Rx Frequency (in MHz)
b = Rx Mode
cc.cccccc = Rx Symbol Rate
d = Rx FEC Type
e = Rx Modulation Type
f = Rx FEC Rate
ggg = Rx Sweep Width
h = Rx Adaptive Equalizer
i = Rx Alpha Roll-off
j = Rx Frame Size
k = Rx Pilots
llllll = Rx Gold Code Sequence
mm.m = Rx EbNo Alarm Point
n = Rx Transport Stream
o=Rx PLL
p=Ber Threshold
xxxxxxxx = Spare bytes.
same as TFQ
(read-only)
same as TSR
same as TFT (read-only)
same as TMD
same as TCR
same as TSI
same as TPL
same as TXO
same as TAR
same as TFS
same as TPI
same as TLP
(read-only)
same as RFQ
(read-only)
same as RSR
same as RFT (read-only)
same as RMD (read-only)
same as RCR (read-only)
same as RSW
same as AEQ
same as RAR
same as RFS (read-only)
same as RPI (read-only)
same as RGS
same as EBA
(read-only)
same as RPL
same as BTH
A–45
Revision 1
MN-CDM710G
