Errata A for MN‐CDM710G Rev 1
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Query
Faults and
N/A
4 bytes
Status
ER-CDM710G-EA1
Description of Arguments
Query Only.
Unit returns the current fault and status codes for the Unit (hardware), Tx Traffic and
Rx Traffic, in the form abcde, where:
a = Unit Faults:
0=No faults
1=Framer FPGA Load
2=Power supply fault, +1.5 Volts, Framer Card
3=Power supply fault, +1.5 Volts, Interface #1
4=Power supply fault, +1.5 Volts, Interface #2
5=Power supply fault, +3.3 Volts, Framer Card
6=Power supply fault, +5.0 Volts, Framer Card
7=Power supply fault, +12.0 Volts, Framer Card
8=Power supply fault, -12.0 Volts, Framer Card
9=Power supply fauilt, +18.0 Volts, Framer Card
A=FLASH Checksum
B=FEC1 Load
C=FEC2 Load
D=Interface #1 Load
E=Interface #2 Load
F=192 MHz PLL
G=External Reference
H=Framer Card Temperature
I=Modem Temperature
J=Cooling Fans
K=Interface #1 Removed
L=Interface #2 Removed
b = Tx Traffic Status:
0=No faults
1= +1.5V Power Supply Unit (Modulator Card)
2= FPGA Failed to Load (Modulator Card)
3= Symbol Rate PLL Clock
4= Tx Synthesizer Unlocked
5= Tx Digital Clock Manager Unlocked
6= I & Q Baseband Channels are Inactive
7= FPGA Temperature (Modulator Card)
8= Reserved
9= TX Clock Failure (Interface 1)
THIS DOCUMENT IS NOT SUBJECT TO REVISION/UPDATE! PLM CO C-0025029
Response to
FLT?
FLT*
Update 'FLT' Serial Remote Control Query
Query
(Instruction
Response to Query
Command
Code and
Qualifier)
FLT?
FLT=abcde
d=
New faults since last check
Note: Each section has faults
listed in order of priority. For
each section, only the highest
priority fault is returned. There
maybe multiple faults for each
section, but only the highest fault
is returned.
Page 3 of 4
