CDM-710G High-Speed Satellite Modem
Front Panel Operation
6.1.4

Menu Matrix

Sect.
6.2 Opening Screen
6.3 Select (Main) Menu
6.3.1 Configuration
6.3.1.1 (CONFIG:) Remote Control
6.3.1.2 (CONFIG:) Tx
6.3.1.3 (CONFIG:) Rx
(CONFIG:) Intfc1
6.3.1.4
(CDI-10-1 E3T3STS1 Interface only)
(CONFIG:) Intfc1
6.3.1.5
(CDI-60 HSSI Interface only)
(CONFIG:) Intfc2
6.3.1.6
(CDI-70 Gigabit Ethernet Interface only)
6.3.1.7 (CONFIG:) Ref
6.3.1.8 (CONFIG:) Aux
6.3.1.9 (CONFIG:) Alarms
6.3.2 Monitor
6.3.2.1 (Monitor:) Alarms
6.3.2.2 (Monitor:) Rx Stats
6.3.2.3 (Monitor:) Event-Log
6.3.3 Test
6.3.4 Info
6.3.5 Save/Load
6.3.5.1 (Save/Load:) Save
6.3.5.2 (Save/Load:) Load
6.3.6 Utility
6.3.6.1 (Utility:) RT-Clk
6.3.6.2 (Utility:) Ref
6.3.6.3 (Utility:) ID
6.3.6.4 (Utility:) Display
6.3.6.5 (Utility:) Firmware
6.3.6.6 (Utility:) FAST
Notes:
1. Because the CDM-710G operates only in DVB-S2 mode, many of the Rx parameters are read-
only.
2. Refer to CONFIG: Tx
3. The Impedance selection appears when the 70/140 MHz Modulator card is installed.
4. Because the CDM-710G operates only in DVB-S2 mode, the Scrambler and pilot selections are
always available.
Description
SymRate for the Data Rate table.
Select: Config; Monitor; Test; Info; Save/Load; Util
Select: Remote; Tx; Rx: Int1; Int2; Ref, Aux, Alarms
Select: Local; Serial; Ethernet
Select: FEC; Mod; Code; SymRate; Freq, Pwr; Scram
Select: FEC; Dem; Code; SymRate; Freq; Eb/No; PLL
Select: Tx; Rx; Config
Select: Tx, Rx, CTS/RTS
Select: Tx; Rx; Man; Stats; SWOP
Select: Ena/Dis; Force (1:1)
Select: Tx; Intfc1; Intfc2
Select: Alarms; Rx_Stats; Event-Log
Select: Transmit; Receive; Unit
Select: View; Clear-All
Select: Mode
Select: Rem; Tx; Rx; Intfc1; Intfc2
Select: Save; Load
Select: RT-CLK; Ref; ID; Display; Firmware; FAST
Select: Info; Select
Select: Cnfg; View
6–5
Revision 1
MN-CDM710G
Remarks
