Comtech EF Data CDM-710G Installation And Operation Manual page 204

CDM-710G High-Speed Satellite Modem
Remote Control
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Real-time Clock TIM= 6 bytes
Time
Tx Location of TLP= 1 byte
the Pilot
Temperature N/A 3 bytes
Tx Pilot On/Off TPI= 1 byte
Tx Power Level TPL= 5 bytes
Tx Spectrum TSI= 1 byte
Invert
Unit Test Mode TST= 1 byte
Description of Arguments
Query
Command or Query.
A time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Command or Query.
Tx Pilot On/Off selection, where:
0=Average,
1=Peak
Example: TLP=0 (which is Pilot Average)
Query Only.
Unit returns the value of the internal temperature, in the form of sxxx
(degrees C). Where s is the sign and and xxx is the number of degrees.
Example: TMP=+026
Command or Query.
Tx Pilot On/Off selection, where:
0=Off,
1=On
Example: TPI=0 (which is Pilot Off)
Command or Query.
Tx Output power level, where:
s=sign ( + / - )
xx.x = Tx Output power level, +05.0 and –20.0 dBm.
L-Band: -25.0 to –05.0 dBm
70/140 MHz: -20.0 to +00.0 dBm
Note: Beyond –20 dBm is beyond the specification.
Example: TPL = -13.4
Command or Query.
Tx Spectrum Invert selection, where:
0=Normal
1=Tx Spectrum Inverted
Example: TSI=0 (which is normal)
Command or Query.
Test Mode, where:
0=Normal Mode (no test)
1=IF Loop
2=I/O Loop
3=RF Loop
4=Tx CW
5=Tx Alternating 1,0 Pattern
Example: TST=4 (Tx CW)
A–14
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TIM= TIM? TIM=hhmmss
TIM?
TIM*
TIM#
TLP= TLP? TLP=x
TLP?
TLP*
TLP#
TMP? TMP? TMP=sxxx
TMP*
TMP#
TPI= TPI? TPI=x
TPI?
TPI*
TPI#
TPL= TPL? TPL=sxx.x
TPL?
TPL*
TPL#
TSI= TSI? TSI=x
TSI?
TSI*
TSI#
TST= TST? TST=x
TST?
TST*
TST#
Revision 1
MN-CDM710G
