CDM-710G High-Speed Satellite Modem
Remote Control
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Buffer Fill State
N/A
3 bytes
Interface
EFI=
2 bytes
Reference
Clock
E3/T3/STS1
ETS=
2 bytes
Mode Select
Gigabit
GMC?
N/A
Interface
Management
MAC Address
Gigabit
GSW?
N/A
Interface
Software
Revision
Description of Arguments
Query
Query only.
s=Defines which interface slot ( 1 or 2 )
xx = value of the buffer fill state, between 1 to 99%. Returns 00 if
demodulator is unlocked.
Note: Command not valid for GbEI.
Example: BFS=133 (which is 33%, on interface slot 1 channel 1)
Command or Query.
s=Defines which interface slot (1 or 2)
x=EXT CLK (Data Rate Accuracy), where:
0 = 1 MHz
1 = 2 MHz
2 = 2.048 MHz
3 = 5 MHz
4 = 10 MHz
5 = 20 MHz
6 = 34.368 MHz
7 = 44.736 MHz
8 = 51.840 MHz
Note: Command valid only with CDI-10-1 G.703 interface.
Example: EFI=14 (Selects 10MHz on slot 1)
Command or Query.
Sets the E3/T3/STS1 interface card mode, where:
s=Interface Slot (1 or 2)
)
m=Mode
0=E3
1=T3
2=STS1
Note: Command valid only with CDI-10-1 G.703 interface. This sets the
selected G.703 data rate. The unit will adjust the symbol rate based on
modulation type and code rate to keep the selected data rate.
Example: ETS=11 (sets Interface 1, Port 1 to T3 mode)
Query Only.
s= Slot 2 Only
Example: To get MAC address for Gigabit in Slot 2
GMC?2
GMC=2;00-06-B0-00-47-17
Query Only.
s= Slot 2 Only
Example: To get Software Revision for Gigabit in Slot 2
GSW?2
GSW=2 FW/12738-,1.1.8,02/16/07
N/A
EFI=
EFI?
EFI*
EFI#
ETS=
ETS?
ETS#
ETS*
GMC?
GMC*
GMC#
GSW?
GSW*
GSW#
A–28
MN-CDM710G
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
BFS?s
BFS=sxx
EFI?s
EFI=sx
(see description of
arguments)
ETS?s
ETS=sm
GMC?s
Gigabit Interface
Management
MAC Address
GSW?s
Gigabit Interface
Software Revision
Revision 1
