Page 1 NX-240/ NX-240V/ NX-340/ NX-340U/ NX-740H/ NX-740HV/ NX-840H/ NX-840HU Function Reference (FUNC) Version: 1.20 Last Updated: September 9, 2016 Language: English Type: © 2016...
Page 3: About This Manual
About this Manual This In-depth manual describes the functions of the NX-240/ NX-240V/ NX-340/ NX-340U/ NX-740H/ NX-740HV/ NX-840H/ NX-840HU transceiver. This document is created for the product having the following design specifications. NX-240/ NX-240V/ NX-340/ NX-340U Item Specifications How to Verify...
Page 4 Notations for the Transceiver Model Names The model names are described collectively as “NX-240/ 240V” or “NX-240/ 240V/ 340/ 340U” in this manual. Also, “Portable” and “Mobile” are designated in this manual as the generic name for a type of transceivers. Transceivers applicable to Portable and Mobile are as follows.
Page 5 Abbreviations Used in this Document Abbreviations Used in this Document The following abbreviations are used in this in-depth manual. Refer to the abbreviation table below. Abbreviation Full Spelling or Meaning Acknowledgment Busy Channel Lockout Beginning of Transmit Channel COM port Communications port Continuous Wave Digital Quiet Talk...
Page 6: Firmware Copyrights
JVC KENWOOD Corporation. Refer to the help texts attached to this software for details. JVC KENWOOD Corporation does not warrant that quality and performance of the software described in this technical document and relevant in-depth manuals conform to the applicability of any use, and JVC KENWOOD Corporation shall be free from liability for any defects, damage or loss, or from any warranty for anything other than what is expressly described in this technical document and relevant in-depth manuals.
Page 7: About Nxdn
About NXDN/ About NEXEDGE About NXDN ® NXDN is the name of the digital air interface protocol and trademark of JVC KENWOOD Corporation and ICOM Inc. It is comprised of a digital radio communications protocol using 4-Level FSK (4LFSK) modulation. About NEXEDGE ®...
Page 8: About The Programming Software
“25.0 kHz (Wide)” for Channel Spacing with a VHF or UHF transceiver in the frequency band regulated by the FCC Part About Options to Use the Functions Described in This Document To use the functions described in this document, the following KENWOOD optional accessories need to be prepared on your own as necessary. Portable/ Mobile Option •...
Page 9: How To Search For Information
How to Search for Information How to Search for Information For your convenience of reading through this document using Adobe Acrobat or Adobe Reader, a link to a corresponding item is pasted in the Contents page, Index page, the lower part of each page and in the context. Clicking the portion where a link is pasted enables a jump to the corresponding page.
Page 10: Outline Of This Transceiver
The text in this document can be searched using the search function of your Adobe Acrobat or Acrobat Reader. Outline of This Transceiver NX-240/ NX-240V/ NX-340/ NX-340U/ NX-740H/ NX-740HV/ NX-840H/ NX-840HU are VHF/ UHF transceivers for the use of professionals. The transceiver is equipped with the existing analog FM mode and the digital communications system which complies with the NXDN common air interface specifications.
Page 11: Digital Modes
Outline of This Transceiver DIGITAL MODES GENERAL • NXDN Digital Air Interface • AMBE+2 VOCODER • 6.25 kHz Channels (Very Narrow) / 12.5 kHz Channels (Narrow) • 64 Radio Access Numbers (RAN) (None and 1 to 63) • Over-the-Air Alias •...
Page 12: About Zones
About Zones About Zones Zone Data Conventional Group Zone Data 2 (Analog, NXDN, Site Roaming or Site Roaming with RAN) Conventional Group Zone Data 1 (Analog, NXDN, Site Roaming or Site Roaming with RAN) Channel Data Channel Data Channel Data Figure 1-1 Zone Description Zone data in a Conventional Group (Analog) or Conventional Group (NXDN) can be configured using KPG-169D/ KPG-170D/ KPG-175D/ KPG-175DN.
Page 13: About Communications Systems
About Communications Systems About Communications Systems The transceiver can transmit and receive by using two communications systems, an Analog Conventional system and an NXDN Conventional system. In each system, the transceiver can communicate in analog mode or the NXDN digital mode. To use the transceiver in each system of the Conventional Group, various parameters for a channel, such as transmit and receive frequencies, and parameters for other various functions related to transmission and reception must be configured for a zone in the Conventional Group by using KPG-169D/ KPG-170D/ KPG-175D/ KPG-175DN.
Page 14: About Communication Methods
About Communication Methods About Communication Methods Following are the communication methods that the transceiver can use. Communication Method Description Available System The transceiver can make following individual or group calls by Voice calls using an NXDN using an NXDN ID. NXDN Conventional System •...
Page 15: Revision History
Revision History Revision History 日付内容 Corrected each version information in “About this Manual”. Added the FPU name “KPG-175DN” and related information. 3) Added "1 W/ 5 W (350 MHz to 400 MHz) Model" and "5 W/ 25 W/ 45 W (400 MHz to 470 MHz) Model" in "GENERAL FEATURES".
Page 16: Table Of Contents
Changing the Brightness of the LED Display FUNCTIONS AND PANEL LAYOUT ..1 (LED Brightness) ..........24 Lighting the LEDs According to the NX-240/ 240V/ 340/ 340U ......1 Transceiver’s Status........25 NX-740H/ 740HV/ 840H/ 840HU....2 SOUND............26 GETTING STARTED ........ 4 Tones that Sound When a User Operates the Connecting the Transceiver to a PC ....
Page 17 CONTENTS Functions Related to the Using the Optional Signaling (NXDN)....55 Volume Configuration........34 Unmuting the Speaker (Audio Control (NXDN))........55 Configuring the Minimum Volume Level Temporarily Disabling the Signaling (Minimum Volume) .......... 34 (Monitor) ............56 Configuring the Maximum Volume Level Unmuting the Speaker by Linking with the (Maximum Volume) .........
Page 18 CONTENTS Storing the Selected or Sent Status Using the Optional Signaling (Analog)..... 94 (Status Hold)............ 74 Unmuting the Speaker Communicating using a CW Message ..75 (Audio Control (Analog))........94 Temporarily Disabling the Signaling Site Roaming..........76 (Monitor) ............95 Site Roaming Behaviors ........
Page 19 CONTENTS 12 DTMF.............132 GTC Count ............ 115 Number of Retries ......... 115 12.1 Sending a DTMF Code Using the Autodial Key Transmit Busy Wait Time ......116 (Autodial)............ 133 Maximum ACK Wait Time ......116 ACK Delay Time ..........116 Autodial List ...........
Page 20 CONTENTS 14.1 Placing the transceiver in Scrambler/Encryption Status Memory ... 171 Emergency Mode ........151 Emergency-key Delay Time ......152 16 SCAN ............172 Manual Emergency Reset ......152 Suspended Power-off ........152 16.1 Starting the Scan........172 14.2 Zone-Channel Used for 16.2 Scanning the Specific Channel Preferentially Emergency Mode ........
Page 21 CONTENTS 19 FUNCTIONS LINKED WITH A VEHICLE ..........188 19.1 Turning the Transceiver ON or OFF by Linking with the Ignition Sense Port Status (Ignition Sense) .......... 188 The Amount of Time until the Transceiver Is Turned OFF (Timed Power-off) ..... 188 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert).....
Page 22: Contents By Purpose
CONTENTS BY PURPOSE Basic Configura- Configuring Various Functions for the Assigning Functions to the Keys on Transceiver the Transceiver tions for Using the Transceiver Frequencies and signaling for transmission and Various functions can be assigned to the PF keys reception, channel data including the transmit on the transceiver.
Page 23 CONTENTS BY PURPOSE Sound Tones Used for the Transceiver Changing the Calling Alert Tone Various tones sound from the transceiver The tone that sounds from the transceiver when according to the operation of the transceiver. the transceiver receives an Individual Call or a Group Call can be changed to the desired tone.
Page 24 CONTENTS BY PURPOSE Avoiding Interference with Other Using Sound to Notify the Reception Communications By sending a tone, a user can notify the other party that the transceiver is receiving a call. If a channel to be used for the transceiver to transmit is being used by other parties, the transmission of the transceiver on the channel is automatically restricted.
Page 25 CONTENTS BY PURPOSE Other Convenient Locking the Transceiver Keys Reducing Battery Consumption (Portable Only) (Portable Only) Functions By locking the transceiver keys, a user can avoid The power consumption of the transceiver can be erroneous operation of the transceiver caused by reduced by setting the transceiver receiving physically contacting the transceiver while intermittently.
Page 26: Functions And Panel Layout
FUNCTIONS AND PANEL LAYOUT NX-240/ 240V/ 340/ 340U Figure 1-1 NX-240/ 240V/ 340/ 340U Front View Antenna Microphone Audio is input to the microphone. Selector Speaker A channel can be changed. The received audio and various tones sound from the speaker.
Page 27: Nx-740H/ 740Hv/ 840H/ 840Hu
1 FUNCTIONS AND PANEL LAYOUT 1.2 NX-740H/ 740HV/ 840H/ 840HU NX-740H/ 740HV/ 840H/ 840HU Figure 1-3 NX-740H/ 740HV/ 840H/ 840HU Front View (Front Panel) ] (Power) Switch Transmit LED/ Busy LED This LED lights when the transceiver transmits or The transceiver is turned ON when this switch is pressed and the transceiver is turned OFF when this receives a signal.
Page 28 1 FUNCTIONS AND PANEL LAYOUT 1.2 NX-740H/ 740HV/ 840H/ 840HU Figure 1-4 NX-740H/ 740HV/ 840H/ 840HU Back View (Rear Panel) D-sub 15-pin Connector (Mobile Only) A PC or external equipment can be connected to the D-sub 15-pin connector via a connection cable, such as KCT-60. 3.5D Jack Connector An external speaker can be connected to the 3.5D jack connector.
Page 29: Getting Started
GETTING STARTED When the transceiver is turned ON after the battery (Portable) or the power source (Mobile) is attached to the transceiver, the transceiver starts up. To make the transceiver ready for use, the configuration data needs to be created using KPG-169D/ KPG-170D/ KPG-175D and written to the transceiver.
Page 30 2 GETTING STARTED 2.1 Connecting the Transceiver to a PC  Using the KPG-22U: KPG-22U To a 2.5/ 3.5D Connector To a USB Port Mobile The transceiver and a PC need to be connected by using the KPG-46A or KPG-46U programming cable. Refer to the figure below: ...
Page 31: Writing The Configuration Data To The Transceiver
2 GETTING STARTED 2.2 Writing the Configuration Data to the Transceiver  Using the KPG-46U: To the Microphone Connector KPG-46U To a USB Port Writing the Configuration Data to the Transceiver Selecting “Write Data to the Transceiver” from the Program pulldown menu in the main window of KPG-169D/ KPG-170D/ KPG-175D opens the Write Data to the Transceiver dialog box.
Page 32: Reading The Configuration Data From The Transceiver
2 GETTING STARTED 2.3 Reading the Configuration Data from the Transceiver/ 2.4 Embedding a Message in the Transceiver (Embedded Message) Reading the Configuration Data from the Transceiver To change the data configured in the transceiver, read the configuration data from the transceiver to KPG-169D/ KPG-170D/ KPG-175D, and then write the configuration data to the transceiver after the configuration data has been changed.
Page 33: Embedded Message With Password
2 GETTING STARTED 2.4 Embedding a Message in the Transceiver (Embedded Message) Embedded Message with Password Embedded Message with Password can be used to store with a password a maximum of 64 alphanumeric characters and symbols in the transceiver. The transceiver profile information, such as the control number and the file name of configuration data written in the transceiver, can be embedded with a password.
Page 34: Basic Operations
BASIC OPERATIONS Turning the Transceiver ON/ OFF Turning the Transceiver ON Portable A Power-on Tone sounds from the transceiver by rotating the Power switch clockwise and the transceiver will be turned If no data is written to the transceiver when the transceiver is turned ON, the LED lights orange and red alternately and a Blank Channel Tone continues to sound from the transceiver.
Page 35: Adjusting The Volume Level
3 BASIC OPERATIONS 3.2 Adjusting the Volume Level/ 3.3 Using Function Keys Adjusting the Volume Level Portable Rotating the Volume control clockwise increases the volume level from the speaker, and rotating the Volume control counterclockwise decreases the volume level from the speaker. Mobile Pressing the Volume Up key increases the volume level in steps of 1.
Page 36: Mode Reset Timer
3 BASIC OPERATIONS 3.3 Using Function Keys Mode Reset Timer Supported Models: Mobile Mode Reset Timer is the timer to exit Function Mode of the transceiver. By using this function, a user does not need to exit the Function Mode manually. It also helps a user by exiting the Function Mode automatically so as not to remain in Function Mode for too long a time.
Page 37: Changing The Zone
3 BASIC OPERATIONS 3.4 Changing the Zone/ 3.5 Changing the Channel Changing the Zone To change a zone, a PF key can be used. Pressing the Zone Up key or the Zone Down key while Zone 1 is selected changes the zone to Zone 2. Pressing the Zone Up key or the Zone Down key again changes the zone to Zone 1.
Page 38 3 BASIC OPERATIONS 3.5 Changing the Channel Operating the Transceiver  Using the [ ]/ [ ] key or the [<B] or [C>] key Press the Channel Entry key. The transceiver enters Channel Entry Mode. If the maximum channel number is a two-digit number, “_ _.” appears on the LED display and the dot on the right side blinks. If the maximum channel number is a single-digit number, “_.”...
Page 39: Changing The Zone-Channel With A Single Touch (Direct Zone-Channel)
3 BASIC OPERATIONS 3.6 Transceiver Behavior When the Zone-channel Is Changed Changing the Zone-channel with a Single Touch (Direct Zone-Channel) Supported Models: Mobile Direct Zone-Channel is the function to migrate to the minimum channel in the minimum zone by pressing the Direct Zone- Channel key.
Page 40: Transmitting/ Receiving
3 BASIC OPERATIONS 3.7 Transmitting/ Receiving Note • For Mobile, if “Off” is configured for Voice Announcement, a Tone A sounds from the transceiver when the Zone Up/ Zone Down key or Channel Up/ Channel Down key is pressed. • For Mobile, the zone number is not announced when the Channel Up or Channel Down key is pressed. Transmitting/ Receiving Receiving Received audio sounds from the speaker when the transceiver receives a signal and conditions to unmute the speaker...
Page 41: Locking The Transceiver Keys (Key Lock)
3 BASIC OPERATIONS 3.8 Locking the Transceiver Keys (Key Lock) Locking the Transceiver Keys (Key Lock) Supported Models: Portable Key Lock is used to disable the transceiver key operation. This function can be used to avoid erroneous operation of the transceiver by physically contacting the transceiver while a user is carrying it around the waist, etc.
Page 42: Transmission/ Reception
Table 4-1 Transmit/ Receive Frequency Range and Step Size Transmit/ Receive Frequencies Model Range In steps of NX-240/ NX-240V 2.5 kHz, 3.125 kHz, 5 kHz, 136 MHz to 174 MHz NX-740H/ NX-740HV 6.25 kHz, 7.5 kHz 450 MHz to 520 MHz...
Page 43: Channel Spacing
4 TRANSMISSION/ RECEPTION 4.3 Channel Spacing/ 4.4 Beat Shift Mobile For Mobile, a user can use the transceiver by switching the transmission power to high, mid, or low power. If the transceiver is located near repeaters or target party, a user can set the transmission power to be lower in order to avoid causing unnecessary radio interference to other transceivers.
Page 44: Indication And Display
INDICATION AND DISPLAY The transceiver is equipped with the LED to be used for notifying a user of the transceiver status, such as transmitting or receiving. The timing to light or blink the LED or the color of the LED can be configured by using KPG-169D/ KPG-170D/ KPG-175D. In addition, for Mobile, the LED display can be configured by using KPG-175D.
Page 45: Led Display
5 INDICATION AND DISPLAY 5.4 LED Display LED Display Supported Models: Mobile Mobile is equipped with the 2-digit 7-segment LED display. A channel number or the transceiver status appears on the LED display. The transceiver displays alphanumeric characters and symbols, or the transceiver status by lighting the 7 bars and the dots.
Page 46: Indication On The Led Display
5 INDICATION AND DISPLAY 5.4 LED Display Indication on the LED Display Supported Models: Mobile Alphanumeric characters and symbols appear on the LED display as below according to the transceiver status: Table 5-1 Indication on the LED Display Status Indication Remarks Displaying the channel number Refer to...
Page 47 5 INDICATION AND DISPLAY 5.4 LED Display Status Indication Remarks NXDN: Refer to 8.11 Disabling the Transceiver Capability by Remote Control (Stun/ Kill) on page Stun state Analog: Refer to 9.10 Disabling the Transceiver Capability by Remote Control (Stun) on page 106.
Page 48 5 INDICATION AND DISPLAY 5.4 LED Display Status Indication Remarks Appears for 1 sec when Horn Alert becomes enabled. Horn Alert Refer to 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) on page 189. Appears for 1 sec when Public Address becomes enabled.
Page 49: Changing The Brightness Of The Led Display (Led Brightness)
5 INDICATION AND DISPLAY 5.4 LED Display Status Indication Remarks NXDN: Refer to 8.10 Sending GPS Data on page Busy state while sending GPS data FleetSync: Refer to 10.7 Sending GPS Data on page 121. Appears for 1 sec when selecting a Priority Channel or when the selected channel is changed to a Priority Channel by using the Priority Zone- Priority Channel...
Page 50: Lighting The Leds According To The Transceiver's Status
5 INDICATION AND DISPLAY 5.5 Lighting the LEDs According to the Transceiver’s Status Configuration using KPG-175D • Configuring the LED Brightness Level ( Edit > Optional Features > Common 1) • Assigning functions to the PF keys ( Edit > Key Assignment) Lighting the LEDs According to the Transceiver’s Status Supported Models: Mobile By using the combination of lighting LED (blue) and 2 dots on the LED display (the left dot and the right dot), the status of...
Page 51: Sound
SOUND Tones that Sound When a User Operates the Transceiver or When the Transceiver Status Is Changed Below is a list of the tones used for the transceiver. Table 6-1 Tone List Tone Description and Type Remarks Power-on Tone Power-on Tone Tone A Tone B Error Tone...
Page 52: Power-On Tone
6 SOUND 6.1 Tones that Sound When a User Operates the Transceiver or When the Transceiver Status Is Changed Power-on Tone A Power-on Tone sounds from the transceiver when the transceiver is turned ON. For Portable, whether to emit the Power-on Tone can be configured using KPG-169D/ KPG-170D. For Mobile, the volume level of Power-on Tone can be configure using KPG-175D.
Page 53: Alert Tone
6 SOUND 6.1 Tones that Sound When a User Operates the Transceiver or When the Transceiver Status Is Changed Function Description This tone sounds from the transceiver when the transceiver initiates an Individual Call Acknowledge Call Request Tone Request in an NXDN Conventional system. (Refer to Notifying the User with a Tone That a Call Request Has Been Initiated (Call Request Tone) on page 64.)
Page 54: Warning Tone
6 SOUND 6.1 Tones that Sound When a User Operates the Transceiver or When the Transceiver Status Is Changed Warning Tone Warning Tone is a tone that sounds from the transceiver before or when the transceiver is disabled to transmit, when the transceiver becomes unable to transmit, or when the transceiver attempts to transmit while the transceiver is unable to transmit.
Page 55: Locator Tone
6 SOUND 6.1 Tones that Sound When a User Operates the Transceiver or When the Transceiver Status Is Changed Locator Tone A Locator Tone sounds from the transceiver before the automatic transmission in Emergency Mode starts and when the automatic transmission ends. Only for Mobile, the volume level of Locator Tone can be configured using KPG-175D.
Page 56: Tones That Sound When The Transceiver Receives A Call
6 SOUND 6.2 Tones that Sound When the Transceiver Receives a Call Tones that Sound When the Transceiver Receives a Call An Alert Tone sounds from the transceiver when the transceiver receives an Individual Call or a Group Call and notifies the user of the reception.
Page 57: Tones That Sound When The Communication Starts/ Ends
6 SOUND 6.3 Tones that Sound When the Communication Starts/ Ends Table 6-10 Alert Tone Pattern Alert Tone Pattern Description The tone frequency can be configured. A frequency between 400 Hz and 2500 Hz can be configured in Frequency steps of 10 Hz. Gap can be configured if “No Tone” is selected. The tone length can be configured.
Page 58: Using Sound To Notify The Other Party That The Communication Ends (Ptt Release Tone)
6 SOUND 6.4 Using Sound to Notify the Reception (Calling Alert Tone) (Analog Conventional System Only) Using Sound to Notify the Other Party that the Communication Ends (PTT Release Tone) PTT Release Tone can be used to notify the receiving party by audible tone that the communication has completed by releasing the PTT switch.
Page 59 6 SOUND 6.5 Functions Related to the Volume Configuration Functions Related to the Volume Configuration The following functions are relevant to the volume configuration: • Minimum Volume • Maximum Volume • Tone Volume Configuring the Minimum Volume Level (Minimum Volume) Portable For Portable, Minimum Volume can be used to retain the minimum volume level even if the Volume control is turned to its lowest level.
Page 60 6 SOUND 6.6 Using the Transceiver as a Megaphone (Public Address) Configuring the Volume Level of Various Tones (Tone Volume) Supported Models: Mobile Tone Volume can be used to adjust the volume level of various tones. This function can be used to maintain the volume level of the tones at a constant level depending on the situation or mute tones.
Page 61 6 SOUND 6.6 Using the Transceiver as a Megaphone (Public Address) Note • While Public Address is enabled, the transceiver cannot transmit. • To use Public Address, an external speaker for Public Address is required. Refer to the service manual for instructions on how to connect an external speaker for Public Address to the transceiver.
Page 62 6 SOUND 6.7 Using Voice Announcement Using Voice Announcement Voice Announcement is the function to inform a user by voice which zone number and channel number have been selected when a Zone-channel is changed. Whether the Scrambler, Encryption, or VOX function (Portable only) is enabled can also be informed by voice.
Page 63 6 SOUND 6.8 Restricting Alert Tone When Consecutively Receiving a Call (Alert Tone Restriction from 2nd Call) (NXDN • Available languages for Voice Announcement are as follows: Portable: English, Spanish, French, and Russian Mobile: English, Spanish, and Russian • The audio of Voice Announcement sounds from the speaker of the transceiver. However, the audio sounds from the external speaker if the external speaker is connected to the transceiver.
Page 64 6 SOUND 6.8 Restricting Alert Tone When Consecutively Receiving a Call (Alert Tone Restriction from 2nd Call) (NXDN  Behavior examples of when the transceiver receives a Group Call If the transceiver receives a Group Call, an Alert Tone does not sound when the transceiver receives a Group Call again using the same Group ID before the time configured for Auto Reset Timer elapses.
Page 65 6 SOUND 6.9 Switching the Internal/ External Speaker (External Speaker) Switching the Internal/ External Speaker (External Speaker) Supported Models: Mobile External Speaker is the function to switch the speaker to be used between the external speaker connected to the D-sub connector of the transceiver and the internal speaker of the transceiver.
Page 66 6 SOUND 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) Audio characteristics for digital communications can be adjusted according to the operating environment of the transceiver. The combination of configurations for each function can customize the audio characteristic according to a user’s operating environment and adjust the audio characteristic of the external microphone connected to the transceiver so that the audio characteristic can be optimal.
Page 67 6 SOUND 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) External Description Microphone Type Enables the capability to adjust the audio characteristics of the following microphones. Portable: Microphone 5 KHS-23 Mobile: KMC-28 Microphone 6 Enables the capability to adjust the audio characteristics of the following microphones. (Portable only) KHS-10 Microphone 7...
Page 68 6 SOUND 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) Table 6-16 Auto Gain Control (RX Audio Response) Auto Gain Control Description Auto Gain Control (RX Audio Response) is disabled and the volume level of the received audio cannot automatically be adjusted. Auto Gain Control (RX Audio Response) is enabled and the volume level of the received audio can automatically High be adjusted to a certain level according to the configuration for the volume level.
Page 69 6 SOUND 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) External Speaker Type Supported Models: Mobile External Speaker Type is the function to configure audio output characteristics for optimal audio quality according to the type of speaker connected to the transceiver. The following are audio sound characteristics of each configuration: Table 6-18 External Speaker Type Speaker Terminal...
Page 70 6 SOUND 6.10 Adjusting Audio Characteristics (NXDN Conventional System Only) If the background noise is loud, the microphone sensitivity may not be properly adjusted. In this case, a user needs to hold the microphone closer and speaks loudly. Table 6-19 Auto Gain Control (TX Audio Response) Auto Gain Control Description Auto Gain Control (TX Audio Response) is enabled and the volume level of the transmitted audio can...
Page 71 BATTERY Supported Models: Portable A user can be notified on the level of the remaining battery power by LED. And, a user can also use the function to save the battery consumption. Warning that the Battery Voltage Is Low (Battery Warning) Battery Warning can be used to notify a user by emitting a beep or blinking the LED when the battery power is low.
Page 72 7 BATTERY 7.2 Reducing Battery Consumption (Battery Saver) Reducing Battery Consumption (Battery Saver) Battery Saver is the function that the transceiver intermittently monitors the presence of a signal while in the standby state to save the battery consumption. By switching the receiver circuit of the transceiver on or off at certain intervals, a user can reduce the battery consumption. If a key has not been pressed for 5 sec or more while no carrier (analog/ digital) or frame synchronization word (digital) exists, the transceiver intermittently monitors the presence of a signal.
Page 73 NXDN CONVENTIONAL SYSTEM NXDN is a generic name for a digital communication system protocol utilizing 4-level FSK. Using NXDN, the transceiver can initiate an Individual Call or Group Call for voice calls, communicate messages using statuses, or send GPS data. In an NXDN Conventional system, communications are realized by sending and receiving digital signals on an NXDN digital channel.
Page 74 8 NXDN CONVENTIONAL SYSTEM 8.1 Initiating Voice Communications (Basic Transmission and Reception) Receiving Received audio sounds from the speaker if the transceiver receives digital signals, and the frequency matches the frequency of the channel on which the transceiver has waited for or the NXDN ID matches the NXDN ID preconfigured for the transceiver.
Page 75 • The received Unit ID Name is different from the ID configured in the Unit ID List or the ID Name stored in the transceiver. • NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU does not support the function to display the ID Name.
Page 76 8 NXDN CONVENTIONAL SYSTEM 8.1 Initiating Voice Communications (Basic Transmission and Reception) TOT Pre-alert TOT Pre-alert is the function to notify a user that a continuous transmission is about to end by the Time-out Timer. The TOT Pre-alert Tone sounds from the transceiver before the transceiver stops the continuous transmission by the Time-out Timer.
Page 77 8 NXDN CONVENTIONAL SYSTEM 8.1 Initiating Voice Communications (Basic Transmission and Reception) The transceiver considers a retransmission within this configured length of time as a continuous transmission. In the following example, the counting of Time-out Timer continues because the transmission was started by a user pressing the PTT switch while the TOT Reset Time was counting down.
Page 78 8 NXDN CONVENTIONAL SYSTEM 8.1 Initiating Voice Communications (Basic Transmission and Reception) Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Busy Channel Lockout (NXDN) ( Edit > Zone Information > Channel Edit > Page 1) Preferentially Using a Channel Being Used by Other Parties (BCL Override) BCL Override can be used to transmit on a busy channel even if Busy Channel Lockout is activated and transmission is restricted.
Page 79 8 NXDN CONVENTIONAL SYSTEM 8.1 Initiating Voice Communications (Basic Transmission and Reception) Operating the Transceiver  Enabling the Talk Around Press the Talk Around key while Talk Around is disabled. A Tone A sounds from the transceiver and Talk Around becomes enabled. For Mobile, “tA”...
Page 80 8 NXDN CONVENTIONAL SYSTEM 8.2 Using the Signaling Using the Signaling RAN code is the signaling to be used for facilitating communication within a group if the same channel is shared by several groups. Also, NXDN ID can be used as the Optional Signaling to initiate a selective call. Sharing the Same Channel (Frequency) by Several Groups (RAN) RAN (Radio Access Number) is a digital signaling type having the same function as analog QT tone or DQT code.
Page 81 8 NXDN CONVENTIONAL SYSTEM 8.2 Using the Signaling Table 8-4 Audio Control (NXDN) Configuration Description The transceiver unmutes the speaker if the received RAN code matches the RAN code preconfigured for the transceiver. Conditions remain unchanged even if the transceiver transmits. The transceiver unmutes the speaker if the received RAN code matches the RAN code preconfigured for the RAN and Optional transceiver and if the received Optional Signaling matches the Optional Signaling preconfigured for the...
Page 82 8 NXDN CONVENTIONAL SYSTEM 8.2 Using the Signaling Transceiver Operation during the Scan If the Monitor key is pressed during the scan, the scan continues. In this case, the transceiver disables the RAN code and Optional Signaling, and unmutes the speaker upon detection of an NXDN frame in the same manner as when the scan is deactivated.
Page 83 8 NXDN CONVENTIONAL SYSTEM 8.3 Making an Individual Call/ Paging Call Making an Individual Call/ Paging Call Individual Call can be used to initiate a call to a target transceiver individually to establish voice calls. By specifying a Unit ID, the transceiver can initiate a call to the transceiver having the Unit ID. Paging Call is also available to initiate a call to a target transceiver without voice communications.
Page 84 8 NXDN CONVENTIONAL SYSTEM 8.3 Making an Individual Call/ Paging Call Configuration using KPG-169D/ KPG-170D/ KPG-175D • Assigning functions to the PF keys ( Edit > Key Assignment) • Configuring the Selcall on PTT (NXDN) ( Edit > Zone Information > Channel Edit > Page 1) •...
Page 85 8 NXDN CONVENTIONAL SYSTEM 8.3 Making an Individual Call/ Paging Call Configuration using KPG-169D/ KPG-170D/ KPG-175D • Configuring the Alert Tone (Individual) (Unit ID List) ( Edit > NXDN > Unit ID List > Alert Tone > Individual) • Configuring the Alert Tone (Paging) (Unit ID List) ( Edit >...
Page 86 8 NXDN CONVENTIONAL SYSTEM 8.4 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call Restricting IDs for Which the Talkback Is Available (Unit ID Encode Block) Unit ID Encode Block is the Unit ID range that the transceiver can respond (Talkback). Unit IDs to which a user is allowed to respond (Talkback) can be restricted using KPG-169D/ KPG-170D/ KPG-175D.
Page 87 8 NXDN CONVENTIONAL SYSTEM 8.4 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Individual Call Acknowledge Request to be enabled or disabled ( Edit > NXDN > Conventional > Individual Call Acknowledge Request) Initiating an Individual Call (Individual Call Acknowledge Request) An Individual Call (Individual Call Acknowledge Request) can be activated by one of the following methods.
Page 88 8 NXDN CONVENTIONAL SYSTEM 8.4 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call • The transmitting transceiver sends a message requesting another acknowledgment if the time configured for Maximum Acknowledgment Wait Time elapses before receiving a response message from the receiving transceiver. The transmitting transceiver can send a message requesting an acknowledgment up to the number of times configured for Number of Retries until the transceiver receives a response message.
Page 89 8 NXDN CONVENTIONAL SYSTEM 8.4 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call Note • If the time configured for Initiating/Incoming Reset Time elapses while the transceiver is placed in the state mentioned at Step 1, the transceiver resets the standby state, and the display reverts to the channel display.
Page 90 8 NXDN CONVENTIONAL SYSTEM 8.4 Initiating an Individual Call After Ensuring That the Target Party Is Available for Communications (Individual Call Notifying the User with a Tone That a Call Request Is in Progress (Call Processing Tone) The Call Processing Tone is the function to sound a Call Processing Tone from the transceiver until the transceiver receives an acknowledgment message from the receiving transceiver, after the call request for an Individual Call (Individual Call Acknowledge Request) is initiated.
Page 91 8 NXDN CONVENTIONAL SYSTEM 8.5 Making a Group Call Making a Group Call Group Call can be used to initiate a call to a group and establish voice calls in the group. The transceiver can initiate a call to the transceivers having the same Group ID by specifying the Group ID. The transceiver can also initiate a call to all transceivers by specifying the Group ID for which “ALL”...
Page 92 8 NXDN CONVENTIONAL SYSTEM 8.5 Making a Group Call Receiving a Group Call If the received Group ID matches the Group ID configured for the transceiver, the transceiver can receive the Group Call. Note To receive a Group Call in an NXDN Conventional system, “NXDN ID” needs to be configured as the Optional Signaling to be used on the channel.
Page 93 8 NXDN CONVENTIONAL SYSTEM 8.5 Making a Group Call Group ID List The transceiver uses a Group ID configured in the Group ID List to initiate a Group Call in an NXDN Conventional system. The desired Group IDs must be preconfigured using KPG-169D/ KPG-170D/ KPG-175D for the transceiver to initiate a Group Call.
Page 94 8 NXDN CONVENTIONAL SYSTEM 8.6 Common Functions for Data Communications Preventing Reception of a Group Call While the Transceiver Is Receiving an Individual Call (Ignore Group Call during Individual Call) Ignore Group Call during Individual Call is the function that prevents reception of a Group Call while the transceiver is receiving an Individual Call.
Page 95 8 NXDN CONVENTIONAL SYSTEM 8.6 Common Functions for Data Communications Transmit Busy Wait Time The transceiver confirms that the communication channel is available before sending data and then starts sending data when the channel is available. Transmit Busy Wait Time is the duration to wait for the communication channel to become available.
Page 96 8 NXDN CONVENTIONAL SYSTEM 8.6 Common Functions for Data Communications ACK Delay Time ACK Delay Time is the length of time from when the transceiver receives data until the transceiver sends the acknowledgment. ACK Delay Time must be shorter than Maximum ACK Wait Time configured for the transmitting transceiver. The default configuration is normally used.
Page 97 Transceiver Inhibit). However, the transceiver sends the status configured for Default Status if Stun Response Status is not configured. The transceiver sends status 207 if neither Default Status nor Stun Response Status is configured. Note NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU cannot send a Radio Check status message. FUNC (K)/Ver 1.20 CONTENTS...
Page 98 8 NXDN CONVENTIONAL SYSTEM 8.7 Sending a Status Message (Status Call) Configuration using KPG-169D/ KPG-170D/ KPG-175D • Configuring the Default Status ( Edit > NXDN > Status > Option) • Configuring the Stun Response Status ( Edit > NXDN > Status > Option) Status List Status Message must be preconfigured in the transceiver using KPG-169D/ KPG-170D/ KPG-175D prior to the transmission.
Page 99 8 NXDN CONVENTIONAL SYSTEM 8.7 Sending a Status Message (Status Call) AUX Input Status Message Supported Models: Mobile AUX Input Status Message can be used to send the specified Status Message when the AUX Input port goes high level to low level or goes low level to high level.
Page 100 8 NXDN CONVENTIONAL SYSTEM 8.8 Communicating using a CW Message Communicating using a CW Message Continuous Wave (CW) is a radio emission type that is used to send and receive Morse code messages over the air. CW Message is used to send Morse code messages preconfigured in the transceiver by using the PF keys. Pressing the CW Message key causes the transceiver to send a CW Message.
Page 101 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming Site Roaming Site Roaming is the function to migrate automatically to the site (channel) providing better radio environment if a transceiver is operated in the NXDN Conventional system. The transceiver receives a synchronization signal transmitted from the repeaters in multiple sites at regular time intervals, and detects the RSSI level.
Page 102 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming When the transceiver receives a synchronization signal from the repeater, the transceiver basically behaves as follows. Synchronization sign Repeater 1 Repeater 2 Repeater 3 Repeater 4 1 sec. Repeater 5 Roaming Roaming Channel 5 - Channel 4 - Channel 3 - Transceiver...
Page 103 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming • If “Site Roaming with RAN” is configured for Zone Type: If the received RAN code matches that preconfigured for the channel, the transceiver unmutes the speaker and the channel will be the Revert Channel. If the received RAN code does not match the RAN code preconfigured for the channel or if no RAN code is configured for the channel, the transceiver migrates to the channel having the second strongest RSSI level (for example, Channel 2) and examines whether the received RAN code matches the RAN code preconfigured for the...
Page 104 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming Site Roaming Link Delay Time The length of time until the repeater in each site is activated may vary depending on the site. Site Roaming Link Delay Time is a function to configure the length of time to tolerate, by delaying the time to start searching for a signal on other channel, a variation in time of when each repeater is activated.
Page 105 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming Quick Site Roaming Level Quick Site Roaming Level is the function to allow Site Roaming to behave faster when the transceiver is in an area with a strong signal. If the transceiver receives a signal of which level is higher than that configured for Quick Site Roaming Level during Site Roaming, the channel will be the Revert Channel.
Page 106 8 NXDN CONVENTIONAL SYSTEM 8.9 Site Roaming Off-hook Site Roaming Supported Models: Mobile Off-hook Site Roaming is the function to start the Site Roaming depending on the status of microphone, either on-hook or off-hook. The transceiver behaves as follows according to the configuration for Off-hook Site Roaming. Table 8-10 Off-hook Site Roaming Configuration Description...
Page 107 8 NXDN CONVENTIONAL SYSTEM 8.10 Sending GPS Data 8.10 Sending GPS Data Global Positioning System (GPS) is the system to acquire the current location information of the own transceiver by receiving signals from the Global Positioning System satellites orbiting the earth. The transceiver can send the acquired own location information (GPS data) to the base station.
Page 108 8 NXDN CONVENTIONAL SYSTEM 8.10 Sending GPS Data Sending GPS Data Automatically at Certain Intervals (GPS Report Mode) GPS data can be sent automatically at the intervals configured for GPS Report Interval. This function is used for position management or monitoring of transceivers on a time base by periodically transmitting location information to the base station.
Page 109 8 NXDN CONVENTIONAL SYSTEM 8.10 Sending GPS Data Sending GPS Data Manually by Using a Key (Send the GPS Data) GPS data can be sent manually by a user pressing the Send the GPS data key. Configuration using KPG-169D/ KPG-170D/ KPG-175D Assigning functions to the PF keys ( Edit >...
Page 110 Whether to accept the Remote Kill Message upon the reception can be configured using KPG-169D/ KPG-170D/ KPG-175D. Note • NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU can receive the Remote Control Message; however, it cannot send the Remote Control Message. • GPS data is automatically sent while the transceiver is in Stun state.
Page 111 Note • NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU can receive the message requesting the Remote transmission; however, it cannot send the message requesting the Remote transmission. • The transceiver initiates a continuous transmission only if the message requesting the Remote transmission is received by an Individual Call.
Page 112 ANALOG CONVENTIONAL SYSTEM In an Analog Conventional system, communications are realized by sending and receiving analog signals on an analog channel. The transceiver can make an Individual Call or a Group Call using Optional Signaling such as DTMF, 2-tone, and FleetSync.
Page 113 9 ANALOG CONVENTIONAL SYSTEM 9.1 Initiating Voice Communications (Basic Transmission and Reception) Operating the Transceiver  Squelch Off key Press the Squelch Off key while Squelch Off is disabled. The Busy LED lights and the transceiver unmutes the speaker and opens squelch regardless of the configuration for QT/DQT Decode.
Page 114 9 ANALOG CONVENTIONAL SYSTEM 9.1 Initiating Voice Communications (Basic Transmission and Reception) Note Squelch Level can be configured for a channel only in an Analog Conventional system. Squelch Level 5 is configured for channels not in an Analog Conventional system. Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Squelch Level ( Edit >...
Page 115 9 ANALOG CONVENTIONAL SYSTEM 9.1 Initiating Voice Communications (Basic Transmission and Reception) TOT Rekey Time TOT Rekey Time is the amount of time from when the transceiver stops the transmission by the Time-out Timer until transmission becomes possible again. Example: Time-out Timer: 30 s, TOT Rekey Time: 20 s Release Press Press...
Page 116 9 ANALOG CONVENTIONAL SYSTEM 9.1 Initiating Voice Communications (Basic Transmission and Reception) Avoiding Interference with Other Communications (Busy Channel Lockout (Analog)) Busy Channel Lockout is the function to automatically restrict the transmission so as not to interfere with other communications. If an attempt is made to transmit on a channel that is already being used by other groups, the transceiver automatically restricts the transmission.
Page 117 9 ANALOG CONVENTIONAL SYSTEM 9.1 Initiating Voice Communications (Basic Transmission and Reception) Note For Portable, this function is also activated while the transceiver is transmitting using VOX. For a transmission using VOX, Busy Channel Lockout will temporarily be disabled and the transceiver can transmit if audio is input within 500 ms after the Warning Tone B starts sounding from the transceiver.
Page 118 9 ANALOG CONVENTIONAL SYSTEM 9.2 Using the Signaling Using the Signaling QT/ DQT is the signaling to be used for facilitating communication within a group if the same channel is shared by several groups. Also, DTMF, 2-tone and FleetSync can be used as the Optional Signaling to initiate a selective call. Sharing the Same Channel (Frequency) by Several Groups (QT/DQT) QT/ DQT is the signaling to be used for facilitating communication within a group if the same channel is shared by several groups.
Page 119 9 ANALOG CONVENTIONAL SYSTEM 9.2 Using the Signaling Using the Optional Signaling (Analog) Optional Signaling is the signaling used to initiate a selective call. DTMF, 2-tone, or FleetSync is the Optional Signaling which can be used in an Analog Conventional system. All signaling types use audible frequencies. (Refer to 9.4 Using 2- tone to Initiate a Selective Call on page 100,...
Page 120 9 ANALOG CONVENTIONAL SYSTEM 9.2 Using the Signaling The conditions to unmute the speaker when the transceiver does not use a QT tone or a DQT code are as follows: Table 9-5 Audio Control (Analog) (Carrier) Configuration Description Carrier If the transceiver receives a carrier, the transceiver unmutes the speaker. If the transceiver receives a carrier and the received Optional Signaling matches the Optional Carrier + Optional Signaling Signaling preconfigured for the channel, the transceiver unmutes the speaker.
Page 121 9 ANALOG CONVENTIONAL SYSTEM 9.2 Using the Signaling Configuration using KPG-169D/ KPG-170D/ KPG-175D Assigning functions to the PF keys ( Edit > Key Assignment) Transceiver Operation during the Scan If the Monitor key is pressed during the scan, the scan continues. The transceiver operates with Carrier Squelch in the same manner as when not scanning.
Page 122 9 ANALOG CONVENTIONAL SYSTEM 9.3 Changing the Decode/ Encode Combination of QT/DQT to Communicate (OST) Changing the Decode/ Encode Combination of QT/DQT to Communicate (OST) Supported Models: Mobile Operator Selectable Tone (OST) is the function to change the decode/ encode combination of QT/DQT signaling to communicate without changing the transmit and receive frequencies.
Page 123 9 ANALOG CONVENTIONAL SYSTEM 9.3 Changing the Decode/ Encode Combination of QT/DQT to Communicate (OST) Placing the Transceiver in Operator Selectable Tone Mode by using the Microphone Keypad (Direct OST) If “Operator Selectable Tone” is configured for Keypad Operation, the transceiver can enter Operator Selectable Tone Mode and the OST number to be used can be selected using the microphone keypad.
Page 124 9 ANALOG CONVENTIONAL SYSTEM 9.3 Changing the Decode/ Encode Combination of QT/DQT to Communicate (OST) Key Operations in Operation Selectable Tone Mode Supported Models: Mobile If the [ ]/ [ ] key or [ ]/ [ ] key to which Zone Up/ Zone Down or Channel Up/ Channel Down is assigned is used while the transceiver is in Operator Selectable Tone Mode, the transceiver exits Operator Selectable Tone Mode and each of the functions is activated.
Page 125 9 ANALOG CONVENTIONAL SYSTEM 9.4 Using 2-tone to Initiate a Selective Call Using 2-tone to Initiate a Selective Call 2-tone signaling uses a pair of 2 different tone frequencies in series. 2-tone is used for a selective call initiated in an Analog Conventional system.
Page 126 9 ANALOG CONVENTIONAL SYSTEM 9.4 Using 2-tone to Initiate a Selective Call Functions Related to 2-tone Code Decoding To decode a 2-tone code using the transceiver, “2-tone 1”, “2-tone 2”, or “2-tone 3” must be configured as an Optional Signaling to be used for the channel. (Refer to Using the Optional Signaling (Analog) on page 94.) The following functions associated with 2-tone Decode can be configured for each 2-tone 1, 2-tone 2, and 2-tone 3:...
Page 127 9 ANALOG CONVENTIONAL SYSTEM 9.4 Using 2-tone to Initiate a Selective Call  Transpond/ Alert Tone Transpond and Alert Tone are functions that allow the transceiver to transmit the multiplexed Transpond tone, or that allow an Alert Tone to sound from the transceiver when the transceiver is called with 2-tone signaling. Table 9-10 Transpond/ Alert Transpond Alert...
Page 128 9 ANALOG CONVENTIONAL SYSTEM 9.4 Using 2-tone to Initiate a Selective Call Clear to Transpond Clear to Transpond allows the transceiver to wait to Transpond until the channel becomes available while other users are using the channel. Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Clear to Transpond to be enabled or disabled ( Edit >...
Page 129 9 ANALOG CONVENTIONAL SYSTEM 9.5 Using FleetSync to Initiate a Selective Call/ 9.6 Using DTMF to Initiate a Selective Call Using FleetSync to Initiate a Selective Call Using FleetSync, the transceiver can initiate an Individual Call, a Group Call, or various message communications in an Analog Conventional system.
Page 130 9 ANALOG CONVENTIONAL SYSTEM 9.7 Using MDC-1200 to Communicate/ 9.8 Sending a PTT ID Using MDC-1200 to Communicate The communication using MDC-1200 is available in an Analog Conventional system. Refer to 11 MDC-1200 on page 126 for details about MDC-1200. Sending a PTT ID PTT ID is a unique transceiver identification code transmitted by pressing or releasing the PTT switch.
Page 131 9 ANALOG CONVENTIONAL SYSTEM 9.9 Improving the Sound Quality for Transmitting and Receiving (Compander)/ 9.10 Disabling the Transceiver Capability by Remote Improving the Sound Quality for Transmitting and Receiving (Compander) Compander is a compound term made from “COMpressor” and “exPANDER”, and is a function designed to improve sound quality.
Page 132 FleetSync FleetSync is a general term for the proprietary KENWOOD message communication system using MSK (Minimum Shift Keying) modulation. The function identifies individual transceivers, and allows for text message and GPS data communications. Note FleetSync can be only used in an Analog Conventional system.
Page 133 10 FleetSync 10.2 Available Calls/ 10.3 Sending a PTT ID 10.2 Available Calls The following various calls are available by using FleetSync IDs. Refer to the instruction for each call for the transceiver operation and behavior. • PTT ID Communications •...
Page 134 10 FleetSync 10.3 Sending a PTT ID Timing for Sending the PTT ID The PTT ID is sent with the following timing:  BOT (Beginning of Transmit) The PTT ID is added to a signal at the beginning of the transmission. Release Press Transmit BOT...
Page 135 10 FleetSync 10.3 Sending a PTT ID Emitting a Tone at the Timing to Send the PTT ID (PTT ID Sidetone) PTT ID Sidetone is the function to emit a PTT ID Sidetone from the speaker of the transmitting transceiver after the transceiver sends the FleetSync ID.
Page 136 10 FleetSync 10.4 Making a Selective Call/ Paging Call Configuration using KPG-169D/ KPG-170D/ KPG-175D • Configuring the PTT ID Pause (Analog) to be enabled or disabled ( Edit > Zone Information > Channel Edit > Page 2) • Configuring the PTT ID Pause Time ( Edit >...
Page 137 10 FleetSync 10.4 Making a Selective Call/ Paging Call Call Type Description This function is used to initiate a call to a party having a FleetSync ID in the same Fleet. Fleet Call The transceiver determines that the received call is a Fleet Call when receiving a Selective Call having the ID configured as “0 (ALL)”...
Page 138 10 FleetSync 10.4 Making a Selective Call/ Paging Call ID List The transceiver uses an individual FleetSync ID to establish communication if FleetSync is enabled. The desired FleetSync IDs must be preconfigured in the transceiver using KPG-169D/ KPG-170D/ KPG-175D prior to use of the transceiver.
Page 139 10 FleetSync 10.4 Making a Selective Call/ Paging Call Selective Call Alert LED Selective Call Alert LED is the function to make the LED blink orange or blue when the transceiver receives a call. A user can notice by the LED that the transceiver is receiving a call. Note The color of the blinking LED can be configured by types of calls by using KPG-169D/ KPG-170D/ KPG-175D.
Page 140 10 FleetSync 10.5 Common Functions for Data Communications Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Auto Reset Timer ( Edit > FleetSync > General 2 > Auto Reset) 10.5 Common Functions for Data Communications The following functions are used in common for data communications such as Status Call or GPS data transmission. •...
Page 141 10 FleetSync 10.5 Common Functions for Data Communications Transmit Busy Wait Time The transceiver confirms that the communication channel is available before sending data and then starts sending data when the channel is available. Transmit Busy Wait Time is the duration to wait for the communication channel to become available.
Page 142 10 FleetSync 10.5 Common Functions for Data Communications Data Transmit Modulation Delay Time Data Transmit Modulation Delay Time is the duration from when the transceiver starts transmitting until the transceiver starts to modulate MSK data. It may be difficult to establish data communications when the transmit and receive frequencies are widely separated or the transceiver is always used in extremely cold areas.
Page 143 10 FleetSync 10.6 Sending a Status Message (Status Call) Note This function can be only used in an Analog Conventional system. Configuration using KPG-169D/ KPG-170D/ KPG-175 Configuring the Data Transmit with QT/DQT to be enabled or disabled ( Edit > Optional Features > Common 1) 10.6 Sending a Status Message (Status Call) Status Message is a simplified messaging system that allows a user to send or receive a status message (Statuses 10 to...
Page 144 10.6 Sending a Status Message (Status Call) The function is not activated for NX-240/ 240V/ 340/ 340U even if the transceiver receives this status. The functions of Motion Detection, Stationary Detection, and Man-down cannot be used for NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU.
Page 145 10 FleetSync 10.6 Sending a Status Message (Status Call) AUX Input Status Message Supported Models: Mobile AUX Input Status Message can be used to send the specified Status Message when the AUX Input port goes high level to low level or goes low level to high level. The transceiver can send a Status Message when a sensor is attached to the AUX Input port and the status of the AUX Input port changes.
Page 146 10 FleetSync 10.7 Sending GPS Data 10.7 Sending GPS Data Global Positioning System (GPS) is the system to acquire the current location information of the own transceiver by receiving signals from the Global Positioning System satellites orbiting the earth. The transceiver can send the acquired own location information (GPS data) to the base station. A GPS receiver unit compatible with the NMEA-0183 standard is required and it must be connected to the communication port of the mobile station transceiver to send GPS data.
Page 147 10 FleetSync 10.7 Sending GPS Data Sending GPS Data Automatically at Certain Intervals (GPS Report Mode) GPS data can be sent automatically at the intervals configured for GPS Report Interval. This function is used for position management or monitoring of transceivers on a time base by periodically transmitting location information to the base station.
Page 148 10 FleetSync 10.7 Sending GPS Data Sending GPS Data Manually by Using a Key (Send the GPS data) GPS data can be sent manually by a user pressing the Send the GPS data key. Configuration using KPG-169D/ KPG-170D/ KPG-175D Assigning functions to the PF keys ( Edit >...
Page 149 10 FleetSync 10.7 Sending GPS Data Sending GPS Data Together With Status Call (GPS Combination) The transceiver can send GPS data by adding the GPS data to a Status Message using FleetSync. To use this function, Status for GPS Combination must be enabled by using KPG-169D/ KPG-170D/ KPG-175D. The range of status numbers to which GPS data can be added can be configured.
Page 150 10 FleetSync 10.8 Disabling the Transceiver Capability by Remote Control (Stun/ Kill) 10.8 Disabling the Transceiver Capability by Remote Control (Stun/ Kill) Stun/ Kill is the function for an administrator to remotely disable the transceiver by using a Remote Stun/ Kill status, for instance, if the transceiver is stolen.
Page 151 MDC-1200 MDC-1200 is the data system using Audio Frequency Shift Keying (AFSK). In this data system, the transceivers communicate at a 1200 baud data rate using 1200 Hz and 1800 Hz tones. Using this data system, a user can send the ID (Own) of the own transceiver as an PTT ID or Emergency ID in the MDC- 1200 format.
Page 152 11 MDC-1200 11.1 Sending a PTT ID  EOT (End of Transmit) The PTT ID is added to a signal at the end of the transmission. Release Press Transmit Figure 11-2 EOT  Both (BOT and EOT) The PTT ID is added to a signal at the beginning and end of the transmission. Press Release Transmit...
Page 153 11 MDC-1200 11.1 Sending a PTT ID Emitting a Tone at the Timing to Send the PTT ID (PTT ID Sidetone) PTT ID Sidetone is the function to emit a PTT ID Sidetone from the speaker of the transmitting transceiver after the transceiver sends the ID (Own) in the MDC-1200 format.
Page 154 11 MDC-1200 11.2 The Transceiver Behavior in Emergency Mode 11.2 The Transceiver Behavior in Emergency Mode Emergency Mode can be used to transmit and receive with the transceiver in emergencies. In such emergency situations, a user can immediately contact the base station by using this function. The transceiver can notify the base station of an occurrence of an emergency situation by sending an Emergency Alarm Request message or an Emergency ID in the MDC-1200 format.
Page 155 • The transceiver does not send an acknowledgment if the received ID does not match the ID preconfigured for the transceiver. • If this function is disabled, the transceiver does not send an acknowledgment. • NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU cannot send a Radio Check command in the MDC-1200 format. Configuration using KPG-169D/ KPG-170D/ KPG-175D •...
Page 156 • The transceiver does not send an acknowledgment if the received ID does not match the ID preconfigured for the transceiver. • NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU cannot send a Stun Request or a Stun Revive Request message in the MDC- 1200 format.
Page 157 Keypad Auto PTT (Mobile only) • Autodial List Selection (Mobile only) • Redial (Mobile only) • PTT ID Communications Note For NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU, DTMF can be used only in an Analog Conventional system. FUNC (K)/Ver 1.20 CONTENTS INDEX...
Page 158 12 DTMF 12.1 Sending a DTMF Code Using the Autodial Key (Autodial) 12.1 Sending a DTMF Code Using the Autodial Key (Autodial) Supported Models: Portable Pressing the Autodial key sends a DTMF code. By using KPG-169D/ KPG-170D, the DTMF code to be sent can be configured for each channel by selecting one of the DTMF codes in the Autodial List.
Page 159 12 DTMF 12.2 Sending the DTMF Code While Transmitting (Manual Dialing)/ 12.3 Sending the DTMF Code by Pressing a Key on the 12.2 Sending the DTMF Code While Transmitting (Manual Dialing) Supported Models: Mobile If Manual Dialing is enabled, the DTMF code corresponding to a particular key on the microphone keypad can be sent when pressing the key while transmitting by pressing the PTT switch.
Page 160 12 DTMF 12.4 Sending a DTMF Code by Selecting from a List (Autodial Mode) 12.4 Sending a DTMF Code by Selecting from a List (Autodial Mode) Supported Models: Mobile A DTMF code configured for the Autodial List can be selected and sent. The transceiver can enter Autodial Mode and the DTMF codes can be selected using one of the following operations: ...
Page 161 12 DTMF 12.5 Redialing/ 12.6 Sending a PTT ID 12.5 Redialing Supported Models: Mobile A previously sent DTMF code can be sent again. Operating the Transceiver Press the Autodial key or the key on the microphone keypad. The transceiver enters Autodial Mode. “Ad” appears on the LED display. Press the key.
Page 162 12 DTMF 12.6 Sending a PTT ID Timing for Sending the PTT ID The PTT ID is sent with the following timing:  BOT (PTT ID (BOT)) The PTT ID is added to a signal at the beginning of the transmission. Press Release Transmit BOT...
Page 163 12 DTMF 12.7 Disabling the Transceiver Capability by Remote Control (Stun) Muting the PTT ID Tone (PTT ID Mute) PTT ID Mute is the function to unmute after a certain amount of time elapses when the transceiver receives an analog signal.
Page 164 12 DTMF 12.8 Functions Related to DTMF Code Encoding 12.8 Functions Related to DTMF Code Encoding Functions related to DTMF code encoding are shown below: • DTMF Speed • First Digit Delay Time • First Digit Time • * and # Digit Time •...
Page 165 12 DTMF 12.8 Functions Related to DTMF Code Encoding First Digit Time First Digit Time is used to extend the amount of time to send the first digit of the DTMF code when the transceiver starts transmitting the DTMF code. Extending the transmission time for sending the first digit of the DTMF code will prevent the receiving transceiver from failing to receive the incoming DTMF code while the battery saver is active or the transceiver is scanning.
Page 166 12 DTMF 12.8 Functions Related to DTMF Code Encoding Note If the first digit of the DTMF code is the * tone or # tone, the transceiver compares the extension time to send the first digit configured for the First Digit Time with the * and # Digit Time and uses the longer extension time to send the first digit. Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the * and # Digit Time ( Edit >...
Page 167 12 DTMF 12.9 Functions Related to DTMF Code Decoding Reducing the DTMF Data Burst Tones (PTT ID with QT/DQT) PTT ID with QT/DQT is the function to send a QT tone or a DQT code when the transceiver sends a DTMF code on the channel where QT/DQT is used.
Page 168 12 DTMF 12.9 Functions Related to DTMF Code Decoding Table 12-6 Transceiver Configuration Transceiver Standby Code (ID Code) Group Code If the base station initiates a call using the DTMF code “A23”: Only Transceiver V and Transceiver W can receive the call. If the base station initiates a call using the DTMF code “AA5”: Only Transceiver X and Transceiver Y can receive the call.
Page 169 12 DTMF 12.9 Functions Related to DTMF Code Decoding Note • Transpond is not activated when the transceiver receives a Group Call. • If both Alert Tone and Transpond are enabled, an Alert Tone sounds from the transceiver after the Transpond operation is complete. •...
Page 170 GPS FUNCTIONS This chapter describes the common functions relevant to GPS data transmission. The following functions are relevant to GPS data transmission: • GPS Report Mode • Number of Times • GPS Report Interval Time • GPS Time Mark • GPS Message Type •...
Page 171 13 GPS FUNCTIONS 13.3 GPS Report Interval Time/ 13.4 GPS Time Mark 13.3 GPS Report Interval Time GPS Report Interval Time is the interval to send GPS data if “Auto” is configured for GPS Report Mode. GPS data is sent at the intervals configured for GPS Report Interval Time after auto transmission of GPS data is started by the GPS Report Mode function.
Page 172 13 GPS FUNCTIONS 13.5 GPS Message Type/ 13.6 GPS Report on Data Zone-Channel 13.5 GPS Message Type GPS Message Type allows the transceiver to change the length of the message to send GPS data. Table 13-1 GPS Message Type Configuration Operation Full The message to be sent is the GPS data corresponding to $GPGGA, $GPRMC and $GPGLL.
Page 173 The ID of the Target Transceiver (Base Fleet/ Base ID) on page 121.) Note NX-240/ 240V/ 340/ 340U/ 740H/ 740HV/ 840H/ 840HU cannot send a GPS Polling Request. Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the GPS Report Back to Requested ID to be enabled or disabled ( Edit >...
Page 174 COMMUNICATIONS IN AN EMERGENCY Emergency is the function to be used for the transceiver to transmit and receive for emergency purposes. This function is used for a user to immediately contact the base station in emergency situations. The transceiver behaves according to the configurations in Emergency Mode when the transceiver is placed in Emergency Mode.
Page 175 14 COMMUNICATIONS IN AN EMERGENCY Emergency Key Delay Time Lone Worker Interval + Emergency Key Duration of Lone Worker Tone Lone Worker Emergency Mode Emergency Mode Receive Transmit Transmit Duration Duration Receive Duration Transmit Duration of Duration of Duration of Locator Tone 1 Locator Tone 2 Locator Tone 1...
Page 176 14 COMMUNICATIONS IN AN EMERGENCY 14.1 Placing the transceiver in Emergency Mode 14.1 Placing the transceiver in Emergency Mode The transceiver can be manually placed in Emergency Mode using the Emergency key. Operating the Transceiver Portable  Placing the transceiver in Emergency Mode Press and hold the Emergency key for longer than the time configured for Hold Delay.
Page 177 14 COMMUNICATIONS IN AN EMERGENCY 14.1 Placing the transceiver in Emergency Mode Emergency-key Delay Time Supported Models: Mobile Emergency-key Delay Time is the duration from when the Emergency key is pressed until the transceiver enters Emergency Mode. Pressing and holding the Emergency key for the duration configured for Emergency-key Delay Time causes the transceiver to enter Emergency Mode.
Page 178 14 COMMUNICATIONS IN AN EMERGENCY 14.2 Zone-Channel Used for Emergency Mode 14.2 Zone-Channel Used for Emergency Mode The Zone-channel to be used when the transceiver enters Emergency Mode can be configured. Emergency Zone-Channel Type Emergency Zone-Channel Type is the type of a Zone-channel used when the transceiver is placed in Emergency Mode. Emergency Zone-Channel Type can be configured using KPG-169D/ KPG-170D/ KPG-175D.
Page 179 14 COMMUNICATIONS IN AN EMERGENCY 14.2 Zone-Channel Used for Emergency Mode  Fixed • Analog Conventional system The transceiver migrates to the Zone-channel configured for Emergency Zone-Channel (Analog), and then behaves according to the configuration for Emergency ID (Analog). Table 14-4 Emergency ID (Analog) Configuration Description None...
Page 180 14 COMMUNICATIONS IN AN EMERGENCY 14.3 Automatically Transmitting and Receiving in Emergency Mode 14.3 Automatically Transmitting and Receiving in Emergency Mode The number of times for which the transceiver toggles between transmission and reception, or the duration for a single session of automatic transmission or reception in Emergency Mode can be configured.
Page 181 14 COMMUNICATIONS IN AN EMERGENCY 14.3 Automatically Transmitting and Receiving in Emergency Mode Duration of Locator Tone 2 Duration of Locator Tone 2 is the duration to emit an Alert Tone which notifies that the transceiver has completed an automatic transmission in Emergency Mode, and starts receiving. The transceiver automatically repeat transmitting and receiving in Emergency Mode.
Page 182 14 COMMUNICATIONS IN AN EMERGENCY 14.3 Automatically Transmitting and Receiving in Emergency Mode Emergency Microphone Supported Models: Mobile Emergency Microphone is the microphone used while the transceiver is in Emergency Mode. Whether to use the microphone for Emergency installed in the transceiver while the transceiver is in Emergency Mode can be configured using KPG-175D.
Page 183 14 COMMUNICATIONS IN AN EMERGENCY 14.4 Indication and Sound in Emergency Mode 14.4 Indication and Sound in Emergency Mode Functions related to the tone that sounds from the transceiver when the automatic transmission starts or ends in Emergency Mode, and the LED notification in Emergency Mode can be configured. Locator Tone A Locator Tone sounds from the transceiver before the automatic transmission in Emergency Mode starts and when the automatic transmission ends.
Page 184 14 COMMUNICATIONS IN AN EMERGENCY 14.5 ID to Be Sent When Emergency Mode Is Activated 14.5 ID to Be Sent When Emergency Mode Is Activated DTMF code, FleetSync ID, or NXDN ID can be sent as an Emergency ID each time the transceiver starts automatic transmission and reception in Emergency Mode.
Page 185 14 COMMUNICATIONS IN AN EMERGENCY 14.5 ID to Be Sent When Emergency Mode Is Activated Configuration using KPG-169D/ KPG-170D/ KPG-175D Configuring the Emergency DTMF ID ( Edit > Emergency Information > Emergency ID (Analog)) Emergency Call Fleet Emergency Call Fleet is the Call Fleet to be sent first in Emergency Mode if “FleetSync” is configured for Emergency ID (Analog).
Page 186 14 COMMUNICATIONS IN AN EMERGENCY 14.6 Placing the Transceiver in Emergency Mode Using Lone Worker 14.6 Placing the Transceiver in Emergency Mode Using Lone Worker Lone Worker is the function that automatically places the transceiver in Emergency Mode if the transceiver is not operated for a certain period of time.
Page 187 14 COMMUNICATIONS IN AN EMERGENCY 14.6 Placing the Transceiver in Emergency Mode Using Lone Worker  Exiting Lone Worker Mode Do either of the following operations while the transceiver is in Lone Worker Mode: • Press the Lone Worker key. •...
Page 188 Note • The inversion frequency of each Scrambler Code from 1 to 16 can be configured to “Kenwood” or in the range from 2000 Hz to 4096 Hz by using KPG-169D/ KPG-170D/ KPG-175D.
Page 189 • For Portable, the Scrambler Code can be configured for each channel by using KPG-169D/ KPG-170D. • The Scrambler Code whose inversion frequency is configured to “Kenwood” has compatibility with the AQUA scrambler installed in the TK-2200/ TK-3200 series transceiver.
Page 190 15 COMMUNICATION SECURITY 15.1 Built-in Voice Scrambler (Analog) Operating the Transceiver Press and hold the Scrambler/ Encryption Code key. The transceiver enters Scrambler/ Encryption Code Mode. “co” appears on the LED display for 1 sec and then the Scrambler Code configured for the selected channel appears. The right dot blinks at this time. Select a Scrambler Code by pressing the [<B] [C>]...
Page 191 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Scrambler/Encryption Status Memory Scrambler/Encryption Status Memory is the function to retain in the transceiver the Voice Scrambler status of each channel, either enabled or disabled. If this function is enabled, the Voice Scrambler status, either enabled or disabled, is retained even if the channel is changed or the transceiver is turned OFF when the status of Voice Scrambler between enabled or disabled is changed by using the Scrambler/ Encryption key.
Page 192 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Configuration using KPG-169D/ KPG-170D/ KPG-175D • Configuring the encryption key data ( Edit > Encryption) • Configuring the Encryption to be enabled or disabled ( Edit > Zone Information > Channel Edit > Page 2 > Encryption Settings) •...
Page 193 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Configuring the Encryption Key Data Used for Communications Supported Models: Mobile Pressing and holding the Scrambler/ Encryption Code key causes the transceiver to enter Scrambler/ Encryption Code Mode. In the Scrambler/ Encryption Code Mode, the encryption key data used for communications can be configured by selecting the key data from the Multi-key List.
Page 194 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Key Operations in Scrambler/ Encryption Code Mode Supported Models: Mobile If the [ ]/ [ ] key or [ ]/ [ ] key to which Zone Up/ Zone Down or Channel Up/ Channel Down is assigned is used while the transceiver is in Scrambler/ Encryption Code Mode, the transceiver exits Scrambler/ Encryption Code Mode and each of the functions is activated.
Page 195 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Key ID: Any value other than 0 The transceiver searches the encryption key data configured for the transceiver. If the Key ID included in the encryption key data, which was used for encryption of the received communication data, matches the Key ID included in the encryption key data which is configured for the transceiver, the transceiver can use the encryption key data to decrypt the data.
Page 196 15 COMMUNICATION SECURITY 15.2 Encryption (NXDN Digital) Scrambler/Encryption Status Memory Scrambler/Encryption Status Memory is the function to retain the Encryption status, either enabled or disabled, in the transceiver. If this function is enabled, the Encryption status, either enabled or disabled, is retained even if the channel is changed or the transceiver is turned OFF when the status of Encryption between enabled or disabled is changed by using the Scrambler/ Encryption key.
Page 197 SCAN Scan is the function to check whether the transceiver receives a call from other transceivers. The transceiver sequentially checks for availability of a signal on each channel, and the transceiver receives a signal on the channel where the signal is detected. Note Refer to 8.9 Site Roaming on page 76...
Page 198 16 SCAN 16.3 Transceiver Behavior during the Scan Table 16-1 Priority Scan Configuration Description The channel configured for Priority Zone-Channel (Analog) or Priority Zone-Channel (NXDN) is used as the Fixed Priority Channel. For Mobile, “P” appears for 1 sec. Selected The selected channel is used as the Priority Channel.
Page 199 16 SCAN 16.3 Transceiver Behavior during the Scan Transceiver Behavior in the Case that the Scan Cannot Be Resumed During the scan, if the zone is changed manually to a zone that does not satisfy the requirement to resume the scan, the scan continues pausing.
Page 200 16 SCAN 16.4 Common Functions for Scan QT/ DQT - Optional Signaling: OR Behavior If the received QT tone or DQT code matches the QT tone or DQT code preconfigured for the receiving transceiver, the transceivers pauses scanning. The transceiver emits the received audio and then waits to receive an Optional Signaling. The transceiver resumes scanning after the amount of time configured for Dropout Delay Time elapses if the QT tone or DQT code matching state is reset while waiting to receive the Optional Signaling.
Page 201 16 SCAN 16.4 Common Functions for Scan Adding or Deleting a Channel to/from the Target Channels for Scanning (Scan Delete/Add) Supported Models: Mobile Scan Delete/Add is the function to add a channel to the target channels for scanning or delete a channel from the target channels for scanning.
Page 202 16 SCAN 16.4 Common Functions for Scan Configuration Description Priority The transceiver transmits on the Priority Channel regardless of the scanning status. The transceiver transmits on the Priority Channel during the scan. Priority + Talkback The transceiver transmits on the Zone-channel where the transceiver pauses scanning while the scan pauses. Note Talkback is an operation to transmit on the Zone-channel on which the transceiver pauses scanning while the scan pauses.
Page 203 16 SCAN 16.4 Common Functions for Scan Lookback Time B Lookback Time B is the interval time to check the Priority Channel in Priority Scan if the QT tone or DQT code, or RAN code does not match that preconfigured for the transceiver though there is a carrier on the Priority Channel while the transceiver is receiving on a normal channel having a different carrier from the Priority Channel.
Page 204 Supported Models: Portable VOX is the function to start transmitting by speaking into a microphone without pressing the PTT switch. This function can be used when a user cannot press the PTT switch, for instance, when a user is using both hands for other tasks.
Page 205 17 VOX 17.3 Remaining in Transmit Mode after a VOX Transmission Has Finished (VOX Delay Time)/ 17.4 Restricting a VOX Transmission while the Press the switch after VOX Gain Level is changed. A tone sounds from the transceiver and the determined VOX Gain Level value is announced. The transceiver needs to be turned OFF and ON again and activated in user mode.
Page 206 17 VOX 17.5 Disabling the VOX by using the PTT Switch (Cancel Operation)/ 17.6 Notifying a User of the Start of a VOX Transmission with a Tone 17.5 Disabling the VOX by using the PTT Switch (Cancel Operation) Cancel Operation is the function to disable the VOX on a channel when the transceiver transmits on a channel where VOX is enabled by a user pressing the PTT switch.
Page 207 FUNCTION PORTS Supported Models: Mobile For Mobile, the transceiver is equipped with function ports (AUX Input/ AUX Output) that can be programmed for use with the D-sub 15-pin connector located on the rear panel of the transceiver. 18.1 Available Functions for AUX Input Ports Following functions can be assigned to AUX Input ports: Table 18-1 Available Functions for AUX Input Ports Function Name...
Page 208 18 FUNCTION PORTS 18.1 Available Functions for AUX Input Ports Function Name Description Channel Select is the Channel Select port to be used with the Remote Zone-Channel List. The zone-channel of the transceiver can be changed using the external device that is connected to the transceiver. (Refer to 18.4 Migrating to a Zone-channel by Using a Connected External Device (Remote Zone-Channel) on page 186.)
Page 209 18 FUNCTION PORTS 18.1 Available Functions for AUX Input Ports Function Name Description AUX Input Status Message is the trigger port that is used to send a FleetSync or NXDN Status Message. The transceiver sends a Status Message to the ID configured for Target Fleet/ ID (FleetSync) or Base ID (NXDN) when the AUX Input Status Message port goes high level to low level or goes low level to high level.
Page 210 18 FUNCTION PORTS 18.2 Available Functions for AUX Output Ports 18.2 Available Functions for AUX Output Ports The following functions can be assigned to AUX Output ports: Table 18-2 Available Functions for AUX Output Ports Function Name Description None No function is assigned. The output port goes low level while the transceiver is receiving a carrier.
Page 211 18 FUNCTION PORTS 18.3 Status Memory (AUX Output Status Message)/ 18.4 Migrating to a Zone-channel by Using a Connected External Device 18.3 Status Memory (AUX Output Status Message) Status Memory (AUX Output Status Message) is the function used to retain the output status of AUX Output Status Message.
Page 212 18 FUNCTION PORTS 18.4 Migrating to a Zone-channel by Using a Connected External Device (Remote Zone-Channel) Note A zone and channel for which no channel data is configured cannot be configured in the Remote Zone-Channel List. Configuration using KPG-175D • Assigning functions to the AUX Input port ( Edit >...
Page 213 FUNCTIONS LINKED WITH A VEHICLE Supported Models: Mobile When the transceiver is installed in a vehicle, functions linking with a vehicle, such as Ignition Sense or Horn Alert, can be used. 19.1 Turning the Transceiver ON or OFF by Linking with the Ignition Sense Port Status (Ignition Sense) Ignition Sense can be used to automatically turn the transceiver ON or OFF linked with the status of the Ignition Sense port of a vehicle.
Page 214 19 FUNCTIONS LINKED WITH A VEHICLE 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) Horn Alert can be used to activate the Horn Alert port for a certain amount of time when the transceiver receives a call. This function turns headlights On of the vehicle connected to the Horn Alert port and makes the horn sound.
Page 215 19 FUNCTIONS LINKED WITH A VEHICLE 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) Conditions to Activate the Horn Alert The conditions to activate the Horn Alert are as follows. The conditions vary between analog and digital (NXDN). Table 19-1 Conditions to Activate the Horn Alert Zone Type Conditions...
Page 216 19 FUNCTIONS LINKED WITH A VEHICLE 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) Activating the Horn Alert by Linking with the Microphone Hook (Off-hook Horn Alert) Off-hook Horn Alert can be used to activate the Horn Alert function linked with the microphone hook status. Refer to Conditions to Activate the Horn Alert on page 190 for conditions to activate the Horn Alert.
Page 217 TRANSCEIVER DATA PROTECTION WITH PASSWORD The transceiver has password functions for protecting the transceiver operation and the security of the configuration data. 20.1 Password for Transceiver Operation (Transceiver Password) Transceiver Password is the function to protect the transceiver from unauthorized usage. When the transceiver with Transceiver Password configured is turned ON, the transceiver enters Transceiver Password Mode.
Page 218 20 TRANSCEIVER DATA PROTECTION WITH PASSWORD 20.1 Password for Transceiver Operation (Transceiver Password) Mobile  Using the Panel keys Press the key to select the number (0 to 9). Press the [C>] key. The number selected in Step 1 is confirmed. Enter numbers in all digits by repeating Step 1 and 2.
Page 219 20 TRANSCEIVER DATA PROTECTION WITH PASSWORD 20.2 Password for Reading Configuration Data in a PC (Read Authorization Password)/ 20.3 Password for Writing Configuration Data 20.2 Password for Reading Configuration Data in a PC (Read Authorization Password) Read Authorization Password protects the configuration data, such as the operating frequencies, from being read by unauthorized persons if the transceiver should ever be stolen.
Page 220 MODE The transceiver is equipped with Clone Mode to be used for copying the transceiver data to another transceiver and VOX Gain Level Setup Mode to be used for adjusting the VOX Gain Level. The transceiver is also equipped with PC Test Mode to be used for testing transmit and receive capabilities of the transceiver and PC Tuning Mode to be used for adjusting the transceiver by using KPG-169D/ KPG-170D/ KPG-175D.
Page 221 21 MODE 21.3 Testing or Adjusting the Transmit and Receive Capabilities of the Transceiver (PC Test Mode/ PC Tuning Mode) 21.3 Testing or Adjusting the Transmit and Receive Capabilities of the Transceiver (PC Test Mode/ PC Tuning Mode) PC Test Mode can be used to test transmit and receive capabilities of the transceiver by using KPG-169D/ KPG-170D/ KPG-175D.
Page 222 APPENDIX Available Functions for the PF Keys Portable The following functions can be assigned to the PF keys of the transceiver using KPG-169D/ KPG-170D: Table A-1 Available Functions for the PF Keys Function Name Description Available System None Nothing will be activated. The DTMF code corresponding to the list number in the Autodial List configured for the Analog Conventional Autodial...
Page 223 A APPENDIX A.1 Available Functions for the PF Keys Function Name Description Available System In an Analog Conventional system, the transceiver disables QT tone or DQT code and Optional Signaling, and unmutes the speaker upon detection of a carrier. Refer to Temporarily Disabling the Signaling (Monitor) on page Monitor In an NXDN Conventional system, the transceiver disables RAN code and Optional...
Page 224 A APPENDIX A.1 Available Functions for the PF Keys Mobile The following functions can be assigned to the PF keys of the transceiver using KPG-175D: Table A-2 Available Functions for the PF Keys Function Name Description Available System None Nothing will be activated. The DTMF code corresponding to the list number in the Autodial List configured for the Analog Conventional Autodial...
Page 225 A APPENDIX A.1 Available Functions for the PF Keys Function Name Description Available System A user can toggle the Horn Alert between enabled and disabled. Horn Alert Refer to 19.2 Controlling Car Behavior by Linking with the Horn Alert Port Status (Horn Alert) on page 189.
Page 226 A APPENDIX A.1 Available Functions for the PF Keys Function Name Description Available System A user can manually send the received GPS data from an optional GPS receiver unit to Send the GPS the base station via a communication port of the transceiver. data Refer to 8.10 Sending GPS Data on page...
Page 227 A APPENDIX A.2 Available Functions for COM Port Available Functions for COM Port Portable For Portable, the COM port 0 is assigned to the 2.5/ 3.5D connector (TXD/ RXD). The following functions can be assigned to the communication port using KPG-169D/ KPG-170D: Table A-3 Available Functions for COM Ports (Portable) Communication Port Configuration...
Page 228 A APPENDIX A.2 Available Functions for COM Port COM Port Settings Portable By using KPG-169D/ KPG-170D, the following configurations are available for the communication port: Table A-5 COM Port Settings (Portable) Configuration Description Polarity is the logic of data lines for sending GPS data using a communication port. Polarity is fixed at Normal, and Polarity this configuration cannot be changed.
Page 229 The command sequence of this version starts with STX (Start of Text) and ends with ETX (End of Text). This version Version 1 is compatible with transceivers that support the Kenwood PC Interface Protocol. This version is almost the same as the Version 1 data format, but it has the command sequence of Version 1 and a Version 2 sequence number (SEQ).
Page 230 INDEX Avoiding Interference with Other Communications Symbols (Busy Channel Lockout (Analog)) ......91 Avoiding Interference with Other Communications * and # Digit Time ...........140 (Busy Channel Lockout (NXDN)) ......52 Background Transmission ........157 Abbreviations Used in this Document ....... iii About Communication Methods .......
Page 231 INDEX Configuring the Maximum Volume Level Emergency ID ............159 (Maximum Volume) ..........34 Emergency ID (MDC-1200) ........129 Configuring the Minimum Volume Level Emergency LED ............ 158 (Minimum Volume) ...........34 Emergency Microphone ........157 Configuring the Scrambler Code ......164 Emergency Microphone Gain ........ 156 Configuring the Volume Level of Various Tones Emergency Mode Type .........
Page 232 Progress (Call Processing Tone) ......65 Number of Retries ........... 69, 115 Number of Times ........... 145 Key Operations in Operation Selectable NX-240/ 240V/ 340/ 340U ......... 1 Tone Mode ...............99 NX-740H/ 740HV/ 840H/ 840HU ....... 2 Key Operations in Scrambler/ NXDN Conventional System ........
Page 233 INDEX OST Table ..............99 Reading the Configuration Data from the Transceiver ............... 7 Outline of This Transceiver ........viii Receive Duration ........... 156 Over-the-Air Alias .............50 Receiving ............49, 87 Receiving a Group Call ........... 67 Receiving a Selective Call/ Paging Call ....112 Receiving an Individual Call (Individual Call Acknowledge Request) ....
Page 234 INDEX Sending GPS Data Manually by Using a Key The Amount of Time until the Transceiver Is Turned (Send the GPS data) ........84, 123 OFF (Timed Power-off) ......... 188 Sending GPS Data Together With Emergency Call The ID of the Target Transceiver (GPS Combination) ..........84, 124 (Base Fleet/ Base ID) ..........
Page 235 INDEX Unit ID List ..............60 Unmuting the Speaker (Audio Control (Analog)) ..94 Unmuting the Speaker (Audio Control (NXDN)) ..55 Unmuting the Speaker by Linking with the Microphone (Off-hook Decode) (Mobile Only) .......57, 96 Using 2-tone to Initiate a Selective Call ....100 Using DTMF to Initiate a Selective Call ....104 Using FleetSync to Initiate a Selective Call ....104 Using Function Keys ..........10...

This manual is also suitable for:

Nx-240v Nx-340 Nx-340u Nx-740h Nx-740hv Nx-840h ... Show all

Kenwood NX-240 Function Reference

Quick Links

Related Manuals for Kenwood NX-240

Summary of Contents for Kenwood NX-240

This manual is also suitable for:

Table of Contents
