Power supply
Captive
screw
FIGURE 8-1
8.1.2
Replacing the Power Supply
Caution – Use proper ESD grounding techniques when handling components. Wear
!
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing it on any surface.
1. Position the power supply into the chassis.
2. Push the power supply toward the chassis rear, engaging the mounting hooks
(
FIGURE 8-2
P1
Removing the Power Supply
).
Clip
DC Harness
J2603
Chapter 8
Major Subassemblies
J2601
8-3
