FIGURE B-3
TABLE B-3
Pin
1
2
3
4
5
6
7
8
B.3 Fast Wide SCSI (Small Computer System
Interface) Connector
The fast wide SCSI connector is located on the system board back panel.
illustrates the fast wide SCSI connector configuration.
SCSI connector pin assignments.
TPE Connector Configuration
TPE Connector Pin Assignments
Signal Name
tpe0
tpe1
tpe2
Common mode termination
Common mode termination
tpe3
Common mode termination
Common mode termination
8 1
Description
Transmit data +
Transmit data -
Receive data +
Termination
Termination
Receive data -
Termination
Termination
TABLE B-4
Appendix B
FIGURE B-4
lists the fast wide
Signal Descriptions B-5
