Note – XXXX placeholders used in table entries represent numeric values that may
change without notice.
CODE EXAMPLE 3-2
Hardware Power ON
Button Power ON
Button Power ON
@(#) Sun Ultra X UPA/SBus X.X X.X FCS Test PROM Version Xcreated XXXX/XX/XX XX:XX
Clearing DTAGS 0000.0000.0008.0000 Done
Probing keyboard Done
%o0 = 0000.0000.0000.2001
Executing Power On SelfTest
0>@(#) Sun Ultra Enterprise X POST, FCS_Version XX.XX.XX X/XX/XXXX XX:XX XX
1>@(#) Sun Ultra Enterprise X POST, FCS_Version XX.XX.XX X/XX/XXXX XX:XX XX
0> UltraSparcX Version X.X
1> UltraSparcX Version X.X
0 << POST COMPLETE(0) >>
Power On Selftest Completed
Status = 0000.0000.0000.0000 0000.XXXX.XXXX.XXXX XXXX.XXXX.XXXX.XXXX
Software Power ON
3.5

POST Progress and Error Reporting

While POST is initialized, the Caps Lock key on the Sun type-5 keyboard flashes on
and off to indicate that POST tests are being executed. Additional POST progress
indications are also visible when a TTY-type terminal or a tip line is connected
between serial port A (default port) of the system being tested and a POST
monitoring system.
If an error occurs during the POST execution, the keyboard Caps Lock key indicator
stops flashing and an error code is displayed using the Caps Lock, Compose, Scroll
Lock, and Num Lock key indicators. The error code indicates a particular system
hardware failure.
3-10 Ultra 1 Creator Series Service Manual • August 1996
Diag-Level NVRAM variable Set to Min
