Sun Microsystems Ultra 1 Creator Series Service Manual page 91

Note – If a CD-ROM drive or a tape drive is installed in the system, perform Step 3.
3. Replace the drive bracket as follows (
a. Position the drive bracket in the chassis.
b. Slide it away toward the openings in the side of the chassis.
Note – The hooks in the chassis base must lock into the holes in the bottom of the
drive bracket.
c. Route the DC harness through the clip on the side of the drive bracket.
d. Replace the two drive bracket mounting screws.
4. Detach the wrist strap.
5. Replace the system unit cover.
See Section 7.3 "Replacing the Cover" on page 7-3.
6. Power-on the system.
See Section 6.1 "Powering On the System" on page 6-1.
and
FIGURE 8-12 FIGURE 8-13
Chapter 8 Major Subassemblies
):
8-17
