Keyboard and mouse functionality is provided through a DIN8 connector. Sun type-
5 keyboards and a new mechanical mouse are supported.
C.1.9 Printer connectivity
Parallel printer port connectivity is provided with a DB25 connector. This interface
supports up to a 2-Mbyte per second data throughput and is Centronics-compatible.
All SPARC printers are supported.
C.1.10 Audio
Audio includes interface, built-in speaker, and microphone.
C.1.10.1 Interface
The system unit or server includes the Codec for audio functionality. Four external
connectors are supplied: line input, line output, a headphone, and stereo
microphone. All connectors are 0.125-inch (3.18-mm) mini-stereo connectors. Line-in
and line-out support 16-bit CD quality stereo.
function.
TABLE C-2
Port
Headphones
Line Out
Line In
Microphone
1. The Ultra 1 Creator Series microphone port accepts stereophonic input; however, the Sun Microphone II is
a monophonic device. Note also that the older SunMicrophone is not compatible with the Ultra 1 Creator
Series system.
identifies the audio specifications.
TABLE C-3
Audio Port Functions
Function
Connects stereophonic headphones for private listening of audio
output
Connects the system audio output to an external stereophonic
amplifier and loudspeakers
Connects external stereophonic audio sources such as a compact
disc player or cassette tape player to the system
Connects the SunMicrophone
to the system
lists each audio port
TABLE C-2
TM
II (or other suitable microphone
