Removing And Installing Headlight; Replacing Light Bulbs And Gas Discharge Lamps - Skoda Octavia III 2013 Workshop Manual

12 - Control unit for daylight driving light and side light - J860- (LED module) left or -J861- right
❑ Removing and installing
⇒ "2.11 Removing and installing Control unit for daylight driving light and side light J860 (LED module)
left and J861 right", page 95
13 - Performance module for the headlight - J667- left or -J668- right
❑ Removing and installing
⇒ "2.10 Remove and install performance module for the headlight J667 left or J668 right", page 95
2.4

Removing and installing headlight

Removal and installation is done in the same was as for the hal‐
ogen headlight, see
⇒ "1.2 Removing and installing headlight", page 80
2.5 Replacing light bulbs and gas discharge
lamps
⇒ "2.5.1 Replacing light bulb for additional side light", page 91
⇒ "2.5.2 Replacing bulbs for side light and daytime running light
P21/5W", page 92
⇒ "2.5.3 Replacing bulb PYW24Y for the turn signal light",
page 93
⇒ "2.5.4 Replacing the gas discharge lamp ", page 93
The LED module is integrated into the headlight housing and
cannot be changed separately. Replace headlight if there is a
module fault.
2.5.1 Replacing light bulb for additional side
light
Note
Do not touch the glass when installing the light bulb. Your fin‐
♦
gers will leave traces of grease on the glass which then
evaporate when the bulb is switched on causing it to cloud.
♦ Pay attention to the correct fitting and undamaged seals on
the plastic covers as well as the correct positioning of the cov‐
er. Water ingress will destroy the headlight.
Headlights with LED module.
– Switch off the ignition and all electrical components.
– Remove cover -2-.
Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
.
2. Headlights – Bi-xenon headlights
91
