– Disconnect the plug from the button -1- and from the reader
coil -2-.
– Insert two small cross-head screwdrivers (e.g. watch-and-
clock screwdrivers) into the openings -arrows- and press the
sheet pegs.
– Grip the bottom part of the button -1- and press it towards the
outside from the bottom trim panel for steering column.
– When removing the reader coil -2- first of all remove the button,
then carefully unclip the reader coil using the disassembly
wedge - 3409- .
Installing
– If removed, first of all insert the immobiliser reader coil -2- and
lock in place.
– Then insert the button -1- into the bottom trim panel and press
until the interlocking lugs lock into place.
– Mount plug and install the bottom and top steering column trim
panel.
10.7 Lock with control unit for ELV - J764-
⇒ "10.7.1 Fault recognition and fault display", page 133
⇒ "9.3 Removing and installing the ELV J764 ", page 125
10.7.1 Fault recognition and fault display
The lock with the control unit for ELV - J764- is equipped with self-
diagnosis, which facilitates the fault finding.
For fault finding use the ⇒ Vehicle diagnostic tester in the function
"Targeted fault finding".
