– Remove the display unit by pulling on the unlocking tools
-arrows-.
– Release and disconnect the plug connections.
– Press back catches from the side and remove the unlocking
tools.
Installing
Installation is carried out in the reverse order. When installing,
observe the following:
Note
When inserting the display unit ,on no account press on the dis‐
play or on the operating buttons, otherwise they will be damaged.
When replacing the Infotainment display unit pairing see
⇒ "1.5 Electronic anti-theft coding", page 33
1.6.3 Infotainment control unit "Bolero",
"Amundsen" and "Columbus"
Removing
– Remove the data storage device that is still in the Infotainment
control unit ⇒ Infotainment operating manual .
– Switch off the ignition and all electrical components.
Vehicles manufactured up to CW 13/2013:
– Remove the glove compartment ⇒ Body Work; Rep. gr. 70 .
– Put your hand behind the control unit and loosen the cable ties
from the fin on the heating and air conditioning unit.
All vehicles:
– Insert unlocking tools into the openings in the control unit
-see fig.- until there is an audible click.
Note
Mask the lower edge of the assembly opening with commercially
available tape that will not scratch the lining when the connectors
are removed.
– Remove the display unit by pulling on the unlocking tools
-arrows-.
Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
.
1. Multimedia information system – Infotainment
35
