Immobiliser; Immobiliser Control Unit J362 - Skoda Octavia III 2013 Workshop Manual

8

Immobiliser

The model Octavia III features the immobiliser of the fifth gener‐
ation with on-line connection and Download. The main compo‐
nent of the fifth generation immobiliser is a central database, in
which all of the theft-relevant data from the participating control
units is stored. It is not possible to adapt the immobiliser control
units without online connection to this database.
♦ A PIN code request of the immobiliser components by fax or
temporary activation of the components is not possible.
♦ All the components of the immobiliser must be initialised on-
line.
♦ All – even re-ordered – ignition keys are already precoded at
the factory for a specific vehicle and can only be initialised for
this vehicle.
♦ When re-ordering ignition keys, the relevant vehicle identifi‐
cation number must be provided.
♦ In Škoda vehicles it is not possible to adapt the components
of other corporate brands.
Immobiliser components:
– ⇒ "8.1 Immobiliser control unit J362 ", page 167
– ⇒ "8.2 Ignition key", page 168
– Engine control unit - J623- diesel engines ⇒ Engine; Rep. gr.
23 , or petrol engines ⇒ Engine; Rep. gr. 24
⇒ "8.3 New identity when changing all the components",
page 168
⇒ "8.4 System test result (online connection)", page 169
Further information and description of the individual components
⇒ Self-study programme No. 87 ; Immobilisers in Škoda vehi‐
cles .
Immobiliser control unit functions - J362- :
♦ Communication between all the immobiliser components
♦ Encryption of data between the control units involved
Fault recognition and fault display
The immobiliser is equipped with self-diagnosis, which makes
fault finding easier.
For fault finding, use the ⇒ Vehicle diagnostic tester in the mode
"Targeted fault finding".
8.1 Immobiliser control unit - J362-
The immobiliser control unit - J362- is integrated in the dash panel
insert. In the event of control unit failure, the complete dash panel
insert must be renewed.
Adapt immobiliser control unit - J362-
– Connect ⇒ Vehicle diagnostic tester.
– Select the operating mode "Targeted fault-finding" in the ⇒ Ve‐
hicle diagnostic tester.
– Select the "Selected Functions/Components" and subse‐
quently the following menu points using the button "Skip":
♦ Body
♦ Electrical system
Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
167
8. Immobiliser
