Table C‐1. Physical Block Parameter Definitions
Label
PARAMETER_NAME
DIAGNOSIS_EXTENSION
Index RO /
Mode
Number RW
Octet 1
0: DIA_LIMITS - Limits
violation (R)
1: DIA_ADVISORY -
Advisory message
available (R)
Bits 2 - 7: Reserved
Octet 2
0: BM1 -
Drive Current Alert (R)
1: BM2 -
Drive Signal Alert (R)
2: BM3 - Program
Memory Alert (R)
3: BM4 - Static
Memory Alert (R)
4: BM5 -
I/O Processor Alert (R)
5: BM6 - Output Block
Timeout (R)
6: BM7 - Blocks Set To
Default (R)
7: BM8 -
Travel Sensor Alert (R)
Octet 3
0: BM9 - Port A
Pressure Sensor Alert
(R)
1: BM10 - Port B
Pressure Sensor Alert
(R)
14 RO
2: BM11 - Supply
Pressure Sensor Alert
(R)
3: BM12 -
Temperature Sensor
Alert (R)
4: BM13 - Pressure
Fallback (R)
5: BM14 - Supply
Pressure High (R)
6: BM15 - Supply
Pressure Low (R)
7: BM16 -
Temperature High (R)
Octet 4
0: BM17 Temperature
Low (R)
1: BM18 -
Travel Deviation (R)
2: BM19 - Travel Limit
High High (R)
3: BM20 - Travel Limit
Low Low (R)
4: BM21 -
Travel Limit High (R)
5: BM22 - Travel Limit
Low (R)
6: BM23 - Cycle
Counter Alert (R)
7: BM24 - Travel
Accumulator Alert (R)
Initial
Valid Range
Value
0
Blocks— Physical Block
Description
Data Type: Octet String
Contains additional device alerts if
DIAGNOSIS_EXTENSION available bit is set in
DIAGNOSIS parameter
Octets 2 to 6 are related to the binary messages
in the Alarm Transducer block. The bits in Octets
2 to 6 will be set when the corresponding alert in
the Alarm TB is enabled and becomes active.
(R): Indication remains active as long as the alert
is active
(A): Indication is active within 10s, and will be
cleared not later than 10s after the action is
completed
