Table C‐14. Logbook Function Block Parameter Definitions
Label
PARAMETER_NAME
EXECUTION_TIME
NUMBER_OF_PARAMETERS
ADDRESS_OF_VIEW_1
NUMBER_OF_VIEWS
Static Revision
ST_REV
Tag Description
TAG_DESC
Strategy
STRATEGY
Alert Key
ALERT_KEY
TARGET_MODE
Block Mode
MODE_BLK
ACTUAL
PERMITTED
NORMAL
Alarm Summary
ALARM_SUM
CURRENT
UNACKNOWLEDGED
UNREPORTED
DISABLED
BATCH
COMMAND
Index RO / Block
Number RW Mode
0.10
0.11
Octet 1 (MSB):
Slot
0.12 Octet 2 (LSB):
Index of View_1 parameter
for access
0.13
1 RO 0 to 65535
2 RW ALL
3 RW ALL
4 RW ALL 0 to 255
Bit 7: OOS (Causes
COMMAND to change to
RESET)
5 RW ALL
Bit 3: Auto (Causes
COMMAND to change to
START)
Bit 7: OOS
6 RO
Bit 3: Auto
6.1
6.2
6.3
Octet 1:
Bits 0 - 6: Reserved
Bit 7: Update Event - Set
7 RO
after any STATIC
parameter is changed.
Octet 2: Reserved
7.1
7.2
7.3
7.4
8
0: RESET (Causes TARGET_
MODE to go to OOS)
9 RW ALL 5: START (Causes TARGET_
MODE to go to AUTO)
10: CLEAR ALL ENTRIES
Range Initial Value
0
0x1C
0x062C
0x01
0
null
0
0
AUTO
N/A
OOS+AUTO
AUTO
0
0
0
0
5
Blocks —Logbook Function Block
Description
Data Type: Unsigned8
Data Type: Unsigned16
Number of used parameters in the block.
Data Type: Unsigned16
Address of View 1 parameter, see table C‐15.
Data Type: Unsigned8
Number of view objects of the block.
Data Type: Unsigned16
The revision level of the static data associated
with the function block. The revision value will
be incremented each time a static parameter
value in the block is changed.
Data Type: Octet String
The user description of the intended
application of the block.
Data Type: Unsigned16
The strategy field can be used to identify
grouping of blocks. This data is not checked or
processed by the block.
Data Type: Unsigned8
The identification number of the plant unit.
This information may be used in the host for
sorting alarms, etc.
Data Type: DS-37
Target mode of the block
Data Type: DS‐69
Valid Bits: 7:OOS, 4:MAN, 3:AUTO
The actual, target, permitted, and normal
modes of the block.
Target: The requested block mode
Actual: The current mode of the block
Permitted: Allowed modes for Target
Normal: Most common mode for Target
Data Type: DS‐42
Current alert status, unacknowledged states,
unreported states, and disabled states of the
alarms associated with the function block.
Data Type: Octet String
Current active alerts. Cleared after 20s
(condensed status) or 10s (classic status).
Not used
Not used
Not used
Data Type: DS‐67
Not used
Data Type: Unsigned16
This is used to switch on and off as well as
resume or reset the Logbook function block.
