Table C‐1. Analog Output Function Block Parameter Definitions
Label
PARAMETER_NAME
Process Value Scale
PV_SCALE
EU_AT_100%
EU_AT_0%
UNITS_INDEX
DECIMAL_POINT
Readback
READBACK
VALUE
STATUS
Reserved by PI
Remote Cascade Input
RCAS_IN
VALUE
STATUS
Reserved by PI
IN_CHANNEL
OUT_CHANNEL
FSAFE_TIME
FSAFE_TYPE
FSAFE_VALUE
Reserved by PI
Index RO / Block
Number RW Mode
11 RW
11.1
11.2
11.3
11.4
12 RO
13
14 RW ALL
PV_SCALE +/- 10%
15-20
Byte 1: TB_ID = 8
Byte 2: Relative index
21 RW ALL of the TB parameter
80 =
Final_Position_Value
Byte 1: TB_ID = 8
Byte 2: Relative index
22 RW ALL of the TB parameter
57 =
Positioning_Value
23 RW ALL >= 0
0: Value of
FSAFE_VALUE is used
as setpoint, status of
OUT = UNCERTAIN -
Substitute Value
1: Use last valid
setpoint; status of
OUT = UNCERTAIN -
Last usable Value or
24 RW ALL BAD - No comm, no
LUV
2: Actuator goes to
fail-safe position
defined by
ACTUATOR_ACTION
(only useful for
actuators with spring
return); status of OUT
= BAD - non specific
25 RW ALL PV_SCALE +/- 10%
26
Initial
Range
Value
100
0
%
2
0
0
0
0xC4
0x0850
0x0839
2
1
0
Blocks— AO Function Block
Description
Data Type: DS‐68
The high and low scale values, engineering unit
code, and number of decimal places to be used in
displaying the PV parameter and parameters which
have the same scaling as PV.
Data Type: Float
Data Type: Float
Data Type: Unsigned16
Data Type: Integer8
Data Type: 101
Actual position of the device. This can be
characterized or de-characterized depending on
IN_CHANNEL setting.
Data Type: Float
Data Type: Unsigned8
Indicates validity of VALUE.
Data Type: DS‐65
Target SP and status by supervisory host
Data Type: Float
Data Type: Unsigned8
Indicates validity of VALUE.
Data Type: Unsigned16
Defines which transducer parameter provides input
to the AO READBACK parameter.
Data Type: Unsigned16
Defines which transducer parameter receives the
AO output. Select Positioning_Value to control
valve position.
Data Type: Float
Time in seconds from detection of failure of the
actual used setpoint (SP=BAD or RCAS_IN
<>GOOD) to the action of the block if the condition
still exists. A comm timeout changes the status of
the transmitted setpoint to BAD
Data Type: Unsigned8
Defines the reaction of the device if a failure of the
actual used setpoint is still detected after
FSAFE_TIME or if the status of actual used setpoint
is Initiate Fail Safe.
Data Type: Float
Setpoint used if FSAFE_TYPE = 0 and FSAFE is
activated
