Fisher FIELDVUE DVC6200p Instruction Manual page 153

Instruction Manual
D103563X012
Module 14
AO_SP_RDBK_RIN_ROUT_POSD_CKBK(S)
AO_SP_RDBK_RIN_ROUT_POSD_
Module Definition
CKBK(S)
Input data length 15
Output data length 10
Parameter data length 0
Identifiers 0x9E, 0XA9
Module 15
AO_SP_RDBK_RIN_ROUT_POSD_CKBK(L)
AO_SP_RDBK_RIN_ROUT_POSD_
Module Definition
CKBK(L)
Input data length 15
Output data length 10
Parameter data length 0
0xCB, 0x89, 0x8E, 0x8, 0x5, 0x8,
Identifiers
0x5, 0x8, 0x5, 0x8, 0x5
AO_SP_RDBK_RIN_ROUT_POSD_CKBK(S)
AO_SP_RDBK_RIN_ROUT_POSD_CKBK(L)
Readback, remote cascade output,
READBACK,
position discrete, checkback, setpoint,
RCAS_OUT,
remote cascade input
POS_D,
CHECKBACK,
SP, RCAS_IN
Input (master view)
Initial Address
Output (master view)
Initial Address
Module Definitions
June 2017
0
1 READBACK -
2 floating-point number
3
4 READBACK - status
5
6
RCAS_OUT -
floating-point number
7
8
9 RCAS_OUT - Status
10 POS_D
11 POS_D - Status
12
13
CHECKBACK
14
0
1 SP -
2 floating-point number
3
4 SP - status
5
6
RCAS_IN -
floating-point number
7
8
9 RCAS_IN - Status
151
