Instruction Manual
D103563X012
Table C‐6. Discrete Output Function Block Parameter Definitions
Label
PARAMETER_NAME
PV_D
VALUE
STATUS
I/O Options
IO_OPTS
View Lists
View lists allow the values of a set of parameters to be accessed at the same time.
Table C‐7. DO Function Block, View 1
Index Number
1 ST_REV
6.1 MODE_BLK.ACTUAL
6.2 MODE_BLK.PERMITTED
6.3 MODE_BLK.NORMAL
7.1 ALARM_SUM.CURRENT
7.2 ALARM_SUM.UNACKNOWLEDGED
7.3 ALARM_SUM.UNREPORTED
7.4 ALARM_SUM.DISABLED
9.1 SP_D.VALUE
9.2 SP_D.STATUS
10.1 OUT_D.VALUE
10.2 OUT_D.STATUS
14.1 RCAS_IN_D.VALUE
14.2 RCAS_IN_D.STATUS
22.1 RCAS_OUT_D.VALUE
22.2 RCAS_OUT_D.STATUS
33 CHECK_BACK
Index RO /
Mode
Number RW
45 RO
45.1
45.2
Octet 1:
0: Reserved
1: SP_D tracks
READBACK_D in Man
2-3: Reserved
4: SP_D Tracks retained
46 RW OOS
target in MAN
5-6: Reserved
7: Use FSAFE_VALUE on
restart
Octet 2:
0 - 7: Reserved
Parameter
Range Initial Value
Extended Parameters
0
0
0x0000
Blocks— DO Function Block
Description
Data Type: 101
Actual valve position in PV_D units.
Data Type: Unsigned8
Data Type: Unsigned8
Indicates validity of VALUE.
Data Type: Octet String
User options for Output Control.
Bit 4 cannot be set with bit 1
Retained target will be the the current target mode
if the actual mode is MAN. If the target mode is
RCAS, SP will track RCAS_IN parameter.
