Instruction Manual
D103563X012
AO Module
Slot 1 Assignment
Module Module Name
1 EMPTY_MODULE
2 AO_SP(S)
3 AO_SP(L)
4 AO_SP_RDBK_POSD(S)
5 AO_SP_RDBK_POSD(L)
6 AO_SP_CKBK(S)
7 AO_SP_CKBK(L)
8 AO_SP_RDBK_POSD_CKBK(S)
9 AO_SP_RDBK_POSD_CKBK(L)
10 AO_RIN_ROUT(S)
11 AO_RIN_ROUT(L)
12 AO_RIN_ROUT_CKBK(S)
13 AO_RIN_ROUT_CKBK(L)
14 AO_SP_RDBK_RIN_ROUT_POSD(S)
15 AO_SP_RDBK_RIN_ROUT_POSD(L)
Module 2
AO_SP(S)
Module Definition AO_SP(S)
Input data length 0
Output data length 5
Parameter data length 0
Identifiers 0xA4
Module 3
AO_SP(L)
Module Definition AO_SP(L)
Input data length 0
Output data length 5
Parameter data length 0
Identifiers 0x82, 0x84, 0x8, 0x5
Input Bytes Output Bytes
0 0
0 5
0 5
7 5
7 5
3 5
3 5
10 5
10 5
5 5
5 5
8 5
8 5
15 10
15 10
AO_SP(S)
AO_SP(L)
SP Setpoint
Output (master view)
Initial Address 0
1
2
3
4
Module Definitions
June 2017
SP -
floating-point number
SP - status
147
