Fisher FIELDVUE DVC6200p Instruction Manual page 150

Module Definitions
June 2017
Module 4
AO_SP_RDBK_POSD(S)
Module Definition AO_SP_RDBK_POSD(S)
Input data length 7
Output data length 5
Parameter data length 0
Identifiers 0x96, 0xA4
Module 5
AO_SP_RDBK_POSD(L)
Module Definition AO_SP_RDBK_POSD(L)
Input data length 7
Output data length 5
Parameter data length 0
0xC6, 0x84, 0x86, 0x8,
Identifiers:
0x5, 0x8, 0x5, 0x5, 0x5
Module 6
AO_SP_CKBK(S)
Module Definition AO_SP_CKBK(S)
Input data length 3
Output data length 5
Parameter data length 0
Identifiers 0x92, 0xA4
Module 7
AO_SP_CKBK(L)
Module Definition AO_SP_CKBK(L)
Input data length 3
Output data length 5
Parameter data length 0
Identifiers 0xC3, 0x84, 0x82, 0x8, 0x5, 0xA
148
AO_SP_RDBK_POSD(S)
AO_SP_RDBK_POSD(L)
READBACK, Readback, position discrete, setpoint
POS_D, SP
Input (master view)
Initial Address
Output (master view)
Initial Address
AO_SP_CKBK(S)
AO_SP_CKBK(L)
Checkback, SP Checkback, setpoint
Input (master view)
Initial Address
Output (master
view)
Initial Address
Instruction Manual
D103563X012
0
1 READBACK -
floating-point
2
number
3
4 READBACK - status
5 POS_D
6 POS_D - status
0
1 SP -
floating-point
2
number
3
4 SP - status
0
1 CHECKBACK
2
0
1 SP -
floating-point
2
number
3
4 SP - status
