Item
11 The WLAN signal strength is displayed in dBm
12 The WLAN active channel
13 The WLAN SSID
If there is a warning that needs to be displayed while ONINE, a popup message will come onto the screen.
For example, entering Power-Saver mode, Print Head Hot, etc.

Offline (Home) Screen

When the printer is taken OFFLINE using the PAUSE Key
The Home screen will be the first screen seen by the user when transitioning from ONLINE to OFFLINE.
Likewise, it will be the last screen seen by the user before transitioning back ONLINE. The right corner of
the header may include the
Using the navigational keys, the user can move among three options:
•
Wizard – Provides Setup Instruction, Web Resources, and other links to the Printronix website
via QR barcodes for Product Support.
•
Settings – Provides access to the printer menu system for configuration.
•
Calibrate – Makes Calibration convenient and easy to perform when media or ribbon are
installed.
There are also functions for the LEFT and RIGHT SOFT keys. The LEFT SOFT key "Cancel Data" is
present if there is data within the buffer and the setting System > Control > Cancel Operation is enabled.
The RIGHT SOFT key labeled "Info" will show the current configuration as text on the UI and the user can
scroll through the data and/or print if desired.

Wizard

The Wizard has several resources available as shown in the next figures. The greatest benefit of the
Wizard is the first subcategory "Wizards". By highlighting this category (green) and pressing ENTER or the
RIGHT ARROW key, the user can then select the Wizard of choice to run:
•
Printer Setup will help the user choose the proper display language, install ribbon & media, set
media and sensor options, calibrate, and run a test pattern to verify the product is working
properly.
•
Application helps the user setup the menu configuration particular to their label or application
coming from the host system.
•
Print Quality helps the user adjust the printer mechanically, and set Print Speed and Intensity
of the printer. A test printout helps the user in making the choices.
Description
symbol in case there are faults in the system not yet cleared.
, the UI will show the Home screen.
23
