Printronix t8000 Administrator's Manual page 213

Tools > Print Tests > Run Tests
Prints the current printer configuration and helps
Current Config identify the text print quality. Includes printhead
statistical data in the header.
Prints a pattern containing a series of ladder-type bar
code symbols, starting with four and decrementing by
Left Test one symbol on each print until a single symbol prints
on the left side. This pattern helps identify ribbon
wrinkle problems.
Prints a pattern containing a series of ladder-type bar
code symbols, starting with four and decrementing by
Right Test one symbol on each print until a single symbol prints
on the right side. This pattern helps identify ribbon
wrinkle problems.
Combo Test Prints a combined left test and right test.
Ethernet Test Prints the Network Interface statistics.
Prints text and barcodes with the barcodes positioned
at the left and right margins of the standard label media
supplied with the printer. The test automatically
produces output for 4, 6, and 8 inch printers at 203 dpi
Barcode Demo
and 300 dpi.
NOTE: Since this test is designed to prove ODV is
working, the printer is automatically put ONLINE
before printing begins.
Prints detailed information about the most recent
Novram related failure. This option is useful when the
Novram Err Log control panel faults with "Bad NVM" or "ILL NVM" type
errors. Contact the Customer Support Center if
such an error occurs.
Prints various patterns on one page that help in the
assessment of print quality, including Grey,
Print Quality
Checkerboard, and text. Number of patterns depends
on the current form length.
This item appears only if the validator is installed.
ODV Report Prints a report of the validation statistics since the
printer was turned on or since the last data reset.
Factory Default Auto Calibrate
