5.6.19 Remote control

Using protective dust caps!
Protective dust caps protect the connection sockets and therefore the machine against
dirt and damage.
• The protective dust cap must be fitted if there is no accessory component being operated
on that connection.
• The cap must be replaced if faulty or if lost!
The remote controls are operated via the 19-pole remote control connection socket
(analogue) or the 7-pole remote control connection socket (digital), depending on the
model.
5.6.20 R10, R20, R40
Type
Port
Display
Dimensions L x W
x H in mm
Weight in kg
The remote controls are designed specifically for use with welding machines in the Phoenix / alpha Q
range and offer various setting options, depending on the model.
Common features:
• Setting the operating point via the wire speed (single-dial operation)
• Arc length correction
R20:
• Changeover and display of up to ten welding programs.
R40:
• Change over, display, create or change up to 16 welding programs.
• Switch superpulse function on or off.
• Change over between standard MIG welding and pulse arc MIG welding
(if supported by the welding machine).
R10
• Setting the operating point via the wire speed (single-dial operation)
• Arc length correction
099-005023-EW501
09.08.2010
CAUTION
R10
19-pole, analogue 19-pole, analogue
-
180 x 100 x 75 330 x 180 x 95
0.86
Design and function
NOTE
R20
7-pole, digital
Single-digit 16-digit
270 x 150 x 75
2.3
MIG/MAG welding
R40
1.4
