Item Symbol
1
2
3
4
5
6
• Insert the electrode holder or gouge plug into the welding current connection socket (wire feeder) and
lock in place by turning to the right. The welding current polarity is changed by reconnecting the
welding power plug (intermediate hose package) at the power source.
5.5.2

Welding task selection

For selection of the welding task and for general operation see the relevant Control operating instructions.
5.6

Remote control

The remote controls are operated via the 19-pole remote control connection socket (analogue) or
the 7-pole remote control connection socket (digital), depending on the model.
Read and observe the documentation to all system and accessory components!
5.7

Access control

To protect against unauthorised or unintentional adjustment of the welding parameters on the machine,
the control input can be locked with the aid of a key switch.
In key switch position 1 all functions and parameters can be set without restriction.
In key switch position 0 the following functions and parameters cannot be changed:
• No adjustment of the operating point (welding performance) in programs 1–15.
• No change of welding or operating mode in programs 1–15.
• The welding parameters can be displayed but not changed in the control's function sequence.
• No welding task switching (JOB block operation P16 possible).
• No change of special parameters (except P10). Restart required.
5.8

Interfaces for automation

No improper repairs and modifications!
To prevent injuries and damage to the machine, only competent personnel (authorised
service personnel) are allowed to repair or modify the machine.
Unauthorised manipulations will invalidate the warranty!
• Instruct competent personnel (authorised service personnel) to repair the machine.
Accessory components and the power source itself can be damaged by incorrect connection!
• Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
• Comprehensive descriptions can be found in the operating instructions for the relevant ac-
cessory components.
• Accessory components are detected automatically after the power source is switched on.
099-005570-EW501
05.12.2023
Description 0
Electrode holder
Gouging torch
Note the additional system documents!
Connection socket, welding current
Welding current potential of the torch connector for MMA welding or gouging
Intermediate hose package
Power source
Workpiece
Design and function
WARNING
Remote control
