2004 MSX 110
W045304CA / CB / CC (W045304IA / IB / IC)
Length: . . . . 126 in. (320 cm)
Width: . . . . . 48.3 in. (122.6 cm)
Height: . . . . 42.5 in. (108 cm)
Dry Weight: 650lbs. (295 kg)
Category: . . Midsize
Riders: . . . . 1 to 3
Fuel Capacity: 17.8 US Gal. (67.4L)
Emission Certification: Two Star -- Very Low Emission
MSX 110 W045304CB Sarasota Yellow
2004 MSX 110 Emission Certification
The engines in all 2004 MSX 110 Personal Watercraft are certified as Two Star, Very Low Emission engines.
The Two Star label identifies engines that meet the California Air Resources Board (CARB) 2004 exhaust emis-
sion standards. Engines meeting these standards have 20% lower emissions than One--Star -- Low Emission
engines. These engines are equivalent to the U.S. EPA's 2006 standards for marine engines.
Emission Control Information Decals
The emission control information decal is located on the flywheel cover.
2004 MSX 110 Emission Decal
ENGINE FAMILY
FAMILY EMISSION LIMIT
EMISSION CONTROL SYSTEM
FUEL
SPARK PLUG
SPARK PLUG GAP
ADVERTISED HORSEPOWER
ENGINE DISPLACEMENT
1.6
GENERAL INFORMATION
3WEBMO.75H01
36.0 g/kW- -hr
SFI (Sequential Fuel Injection)
Unleaded Gasoline 91 Octane R+M/2
Champion RC7PYCB
.7 - - .8mm (.028 - - .032 in.)
82 kW (110HP)
750cc
2004 Four Stroke PWC Service Manual
