ENGINE DISASSEMBLY / ASSEMBLY
Fuel Rail Specific Fastener Torque Specifications
Component
Fuel Rail Fasteners
Engine Management Components / Sensor Specific Fastener Torque Specifications
Component
Electronic Throttle Body
Wastegate Solenoid Bracket
Knock Sensor
Temperature / Pressure Sensor
(Intercooler - - Air Intake Pipe)
Temperature / Pressure Sensor
(Intake Manifold)
Crank Position / Speed Sensor
Oil Pressure Switch
Coolant Manifold Temp. Sensor
Ignition Coil Fasteners
Spark Plugs
Starter Motor Fasteners
Balance Plate / PTO Specific Fastener Torque Specifications
Component
Balance Plate - - to - - Crankshaft
Engine Mounts Specific Fastener Torque Specifications
Component
Front Engine Mount - - to - - Lower
Crankcase
Rear Engine Mount - - to - - Crankcase
Rear Engine mount - - to - - Crankcase
and Lower Crankcase
Intercooler Bracket - - to - - Front Engine
Mount
Intercooler Bracket - - to - - Crankcase
Oil Storage Tank Bracket
2004 Four Stroke PWC Service Manual
FT. LBS. Nm
7 10
FT. LBS. Nm
7 10
7 10
14 20
4 5
5 7
7 10
7 10
13 18
7 10
20 27
7 10
FT. LBS. Nm
51 70
FT. LBS. Nm
40 55
18 25
40 55
7 10
40 55
7 10
Notes Fastener(s)
Loctite 243 M6 x 20
Notes Fastener(s)
M6 x 45
M8 x 30
M6 x 10
M6 x 10
M6 x 10
M10 x 1
M6 x 20
Dielectric Grease
Nyogel M6 x 20
Notes Fastener(s)
Loctite 577 M10 x 1 X 45
Notes Fastener(s)
M10 x 80
M8 x 30
M10 x 40
M6 x 25
M10 x 60
M6 x 25
4.5
